Parameter
Device Sensor Throughput
Limit
Device Command Timeout
Device Stream Channel
Count
Device Reset
Device Temperature Selector
Device Temperature
Find Me
Device Max Throughput (bps) Read only

12.2 Embedded Information in Image

The embedded information function may differ by camera models.
The camera supports adding and embedding the collection information to the image data. You can
set in the client software and define which information to be embedded in the image data.
Embedded information includes following categories: Timestamp, Gain, Exposure, Brightness Info,
White Balance, Frame Counter, Ext Triggering Count, Line Input Output, and ROI Position.
Each category of embedded information has its unique data format.
No. Information Type
1 Timestamp
USB3.0 Board Level Camera
Read/Write Description
Read and It controls device flow, and can be set according to actual
write bandwidth to avoid image lose.
Read only It is the device max. response time.
Read only It is the quantity of device stream channel.
Read and
Click Execute to reset the device.
write
Read and It selects device component temperature.
write
It displays the real-time temperature of the device
Read only component you selected in Device Temperature
Selector.
Read and Click Execute to let red indicator flash once, and find
write device.
It is the maximum flow of device operation.
Table 12-2 Embedded Information Data Format
Byte Data Format Description
4 Bytes 4 bytes are used to transfer the timestamp information.
