6.3.5 Set Frame Grabber Trigger Control

When selecting CC1/CC2/CC3/CC4 as Trigger Source, the camera is in frame grabber trigger status.
Frame grabber triggers camera to acquire images by sending signal via CameraLink cable.

6.4 Trigger Related Parameters

Under external trigger mode, you can set frame burst, trigger delay, trigger activation, shaft
encoder counter, and trigger debouncer. Different trigger modes can set various trigger parameters,
and their relation is shown below.
Trigger Mode
Trigger Parameter
Burst Frame Count
Trigger Delay
Trigger Activation
Shaft Encoder
Counter
Trigger Debouncer
CameraLink Line Scan Camera
Figure 6-24 Set Frame Grabber Trigger
Table 6-3 Trigger Mode and Trigger Parameter
Software Hardware
Trigger Trigger
Support Support
Support Support
Not support Support
Not support Not support Support
Not support Support
User Manual
·
Shaft
Encoder
Control
Not support Support
Support
Support
Support
29
Frequency Frame
Converter Grabber
Control Trigger
Support
Support Support
Support Support
Not support Not support
Support Support
