Grizzly G0554Z Owner's Manual Page 87

14" x 40" gear-head floor lathe.
Hide thumbs
Saddle & cross Slide parts List
REF PART #
DESCRIPTION
501
P0554Z0501
CROSS SLIDE GIB
502
P0554Z0502
GIB ADJUSTMENT SCREW
503
PS09M
PHLP HD SCR M5-.8 X 10
505
P0554Z0505
WIPER PLATE
506
P0554Z0506
CROSS SLIDE BODY
507
P0554Z0507
T-BOLT
508
P0554Z0508
HUB
509
P0554Z0509
BALL OILER 8MM
510
PSB02M
CAP SCREW M6-1 X 20
511
P0554Z0511
SLEEVE
512
PSS20M
SET SCREW M8-1.25 X 8
513
PN02M
HEX NUT M10-1.5
514
P0554Z0514
BEARING CAP
515
PSB07M
CAP SCREW M6-1 X 30
516
P8101
THRUST BEARING 8101
517
P0554Z0517
BLOCK
518
P0554Z0518
SPACER
519
P0554Z0519
CROSS SLIDE LEADSCREW
520
PSB26M
CAP SCREW M6-1 X 12
521
P0554Z0521
LEADSCREW NUT
522
PS49M
PHLP HD SCR M3-.5 X 5
523
PK23M
KEY 5 X 5 X 25
524
P0554Z0524
GEAR SHAFT 20T
525
PK48M
KEY 4 X 4 X 20
526
P0554Z0526
BALL OILER 6MM
527
PS12M
PHLP HD SCR M3-.5 X 6
528
P0554Z0528
INDEX PLATE
529
P0554Z0529
BEARING HOUSING
530
PSB29M
CAP SCREW M6-1 X 40
531
P8102
THRUST BEARING 8102
532
P0554Z0532
END CAP
Model g0554z (Mfg 01/09+)
REF PART #
DESCRIPTION
533
PS09M
PHLP HD SCR M5-.8 X 10
534
P0554Z0534
GRADUATED DIAL
535
P0554Z0535
HANDWHEEL
536
P0554Z0536
HANDWHEEL SCREW
537
PSS12M
SET SCREW M6-1 X 25
538
P0554Z0538
HANDLE
540
P0554Z0540
COMPRESSION SPRING
541
P0554Z0410
STEEL BALL 6MM
542
P0554Z0542
SADDLE
543
P0554Z0543
PIN 6 X 40
544
P0554Z0544
WIPER PLATE
545
PS09M
PHLP HD SCR M5-.8 X 10
547
PSB45M
CAP SCREW M8-1.25 X 45
548
P0554Z0509
BALL OILER 8MM
550
P0554Z0550
WIPER PLATE
551
P0554Z0551
REAR PRESSURE PLATE
552
P0554Z0552
SADDLE GIB
553
PLN03M
LOCK NUT M6-1
554
PSS25M
SET SCREW M6-1 X 20
555
PSB14M
CAP SCREW M8-1.25 X 20
556
P0554Z0556
HANDLE KNOB M10-1.5
557
P0554Z0557
HANDLE LEVER
558
P0554Z0558
HANDLE HUB
559
P0554Z0559
OIL FILL CAP
560
P0554Z0560
LOCK STUD
561
P0554Z0561
FRONT PRESSURE PLATE
562
P0554Z0562
STRAIN RELIEF
563
P0554Z0563
LAMP BRACKET
564
P0554Z0564
WIPER PLATE
565
P0554Z0565
SPECIAL PIN
566
P0554Z0566
SLEEVE
-85-
