NET Series
Software Operation
The WinNET-LT tab is useful in the following situations:
NOTE: The WinNET-LT tab does not prevent two events from occupying the same
time.
 When you would like to use the same event on multiple days, schedule the
event on the WinNET-LT tab once and avoid having to recreate or copy the
event on multiple day tabs.
 If you would like to create a schedule that encompasses more than the next
seven days, use the WinNET-LT tab and schedule according to date.
 Schedule a device-only event without a switch on the WinNET-LT tab to test a
device-only event action before sending it to the destination or to perform
nonplayback events such as recording.
 Schedule event device, library, and switch event actions on the WinNET-LT tab
to edit resource properties and, if desired, ripple changes to all affected playlist
events (you must enable the "global resource property changes" option—see
"Setting WinNET Viewing and Communication Options," on page 63 for more
details).
NOTE:
Channel and Day/WinNET-LT Tab Configurations
Each pair of channel and day tabs displays its own event pane. In addition, the
WinNET-LT tab displays a single event pane, regardless of the channel. Selecting one
of the channel tabs merely causes its output to be the default when adding an event,
with the ability to select a different output. The channel tabs will appear as follows
based on the Controller model (see Table 14, Controller Tab Configurations).
LOADED
CONTROLLER IMAGE
No image loaded
MINI-T-NET
NET-164
NET-EC
Page 90
Resource properties may be edited if the corresponding device,
switch, or library item is scheduled only on the WinNET-LT tab.
Table 14, Controller Tab Configurations
CHANNEL TABS
1 blank tab
 Output 1
 Misc.
 Output 1–Output 4
 Misc.
 Output 1–Output 8
 Misc. (2–9 channels)
Firmware Ver. 1.00.42/Software Ver. 1.0.2.6
# OF EVENT PANES
15 (2 channels x 7 days + 1 WinNET-
LT tab)
36 event panes (5 channels x 7 days +
1 WinNET-LT tab)
From 15 to 64 event panes (2 to 9
channels x 7 days + 1 WinNET-LT tab)
