Leightronix NET Series Manual page 60

NET Series
Software Installation and Configuration
2. Check the boxes in the "Channel/Misc" section to select the channels
that should be included for the selected days.
NOTE:
 Check the "Export/print gaps" checkbox to display playlist gaps.
 Check "Export/print all records" to include all events in the selected event
panes.
NOTE:
 Add/remove playlist fields (columns) in template as follows:
 Add a field to the "Used" list by double clicking a field item in the
"Available" list or selecting it and clicking ">>." The fields in the "Used" list
will be printed/exported in the selection order listed.
 To add a field at a specific point within the "Used" list, highlight the
"Used" display item you would like to display the new field before.
Double click a field item in the "Available" list or select it and click ">>."
The new field is added above the selected field (select the blank field at
the bottom to add a field to the end of the list).
 Remove a "Used" field, by double clicking it or selecting it and clicking
"<<."
c. Click "Save" to save the template to a file.
2. To revise a template:
a. Click "Export/Print templates" in the "Tools" menu to open the window shown in
Illustration 31, "Export/Print Templates" Window.
b. Click "Load." In the "Select Export/Print Template" Window that appears,
browse for the desired template and open. The filename will then appear in the
"Template" box at the top of the "Export/Print Templates" Window.
3. Click "Done" when finished to close the "Export/Print Templates" Window.
Page 58
The channel list varies depending on the Controller.
This function overrides any export or print values set to "No" in the
device, library, or switch tab properties.
Firmware Ver. 1.00.42/Software Ver. 1.0.2.6 LEIGHTRONIX, INC.
2010-07-09
