IP ADDRESS

The IP address screen displays the Controller's IP address on the bottom line of the
screen (see Illustration 92, NET Series IP Address Status Screen).
Wed Oct 10 12:00:00PM
IP:10.2.1.197

NET-164 AND NET-EC ONLY: DVPLY FIRMWARE VERSION

The DVply firmware version screen displays the DVply firmware version of a NET-164
or NET-EC Controller on the bottom line of the screen (see Illustration 94, NET Series
Serial Number and Firmware Version Status Screen).
Illustration 93, NET-164 and NET-EC: DVply Firmware Version Status Screen
Wed Oct 10 12:00:00PM
DVply Ver: 1.0.1.0

SERIAL NUMBER AND FIRMWARE VERSION OF CONTROLLER

The serial and firmware version of the Controller is displayed on the bottom line of this
screen (see Illustration 94, NET Series Serial Number and Firmware Version Status
Screen).
Illustration 94, NET Series Serial Number and Firmware Version Status Screen
Wed Oct 10 12:00:00PM
SN:0201C5

SITE ID

The site ID status screen displays the site ID on the bottom of the screen (see
Illustration 95, NET-164 Site ID Status Screen Example).
Illustration 95, NET-164 Site ID Status Screen Example
Wed Oct 10 12:00:00PM
ID:NET-164
Site ID is entered from the WinNET client software and allows you to define a name for
your NET Series Controller. This is most useful in a multiple Controller system, as
you can then identify each Controller by name in addition to its IP address.
LEIGHTRONIX, INC.
2010-07-09
Illustration 92, NET Series IP Address Status Screen
V1.00.28 Menu~
Firmware Ver. 1.00.42/Software Ver. 1.0.2.6
NET Series
Front Panel Operation
Menu~
Menu~
Menu~
Page 125
