Managing Memories & Chases
66 Event V3 Manual

10.30 Assign Stack

Diagram 10D
When a Stack is assigned it uses two Assign faders. The possible fader pairs are:
1&2, 3&4 ...... 23&24.
The left hand fader controls the Infade rate while the right hand fader controls the
Outfade rate.
The Flash buttons beneath these faders become GO & BACK buttons.
The LED below the Flash buttons illuminates.
Press the Assign button.
1
Press the Stack button to open the Assign Stack menu.
2
Enter the first Memory / Chase number of the Stack.
3
NOTE:
This does not have to be the lowest number in the Stack, just the first number you
want to use.
Press the Flash button beneath the Assign fader to be used to control this
4
Stack.
NOTE:
Two faders are required, and as such the console automatically sets the adjacent
fader.
Once the Flash button has been pressed, the Assign menu is closed and you will see
the Assigned Stack has replaced whatever was previously controlled by the Assign
Masters.

10.40 Special Feature - Assign Edit

If you are used to working with theatrical consoles you may want to record
Memories using the menu system to enter Channel - Thru - At values. Event allows
this but unless the Memory is already recorded you will not be able to put the
memory on an Assign fader and thus be able to see what you are doing.
To get around this problem it is possible to assign the edit output to a fader:
• Press the Assign button followed by the Edit button.
• Press the Flash button beneath the Assign Fader to be used to control the Edit
output
Once the Flash button has been pressed, the Assign menu is closed and you will see
the Edit output has replaced whatever was previously controlled by the Assign
Master.
