Advanced Control; Build - Jands Event Plus Operating Manual

Advanced Features Advanced Features
102 Event V3 Manual

15.00 Advanced Control

15.10 Build

When controlling moving lights and in some theatrical applications it can be useful
to use Memories as "building blocks". In this way Memories that have been "built"
will reflect any changes made in the Memories they are built from. This feature is
commonly used to simplify the refocusing of moving lights when moving from
venue to venue.
A show might include a number of Memories that have moving lights focused on
the lead singer. When the show moves to a new venue the trim height of the truss
might be different or the singer might move to a slightly different position.
Normally all Memories that had lights focused on the singer would have to be edited
to correct the focus.
An easier solution is to record one Memory that focuses the lights on the singer -
that memory ONLY contains Pan and Tilt information. After turning on the Build
record feature the Memory is used when recording any other Memories that have
the lights focused on the singer. Then if the focus needs to be changed its only
necessary to edit the one memory, containing the pan and tilt information to see that
change reflected in all the other memories that were built from it.
EXAMPLE:
The steps below detail an example of how to record a Memory that only includes
position settings and how to build from that Memory:
1. Record a Memory that only controls the Pan an Tilt settings for a number
of lights.
NOTE
: To do this you'll need to have the light on and the iris open so you can see where
it is being focused but remember to pull all the preset faders, except those
controlling Pan and Tilt, down to zero before recording the Memory. That way
only the channels controlling Pan and Tilt will be recorded with a level greater
than 0.
2. Open the Build menu and set the Record field to Build.
3. Make sure the Memory you recorded at step 1 is on the Assign masters. Fade
up the Memory to position the lights.
4. Use the Preset Faders to set Colour, Intensity and so on.
5. Record a new Memory.
This new Memory will now track any changes made to the Memory it was built from.
NOTE
: Built memories are NOT automatically updated if they are on the Assign masters.
The Built memory MUST be reloaded to the Assign faders by changing Page or
Assigning.
