Method 2: Using Assign Flash Button - Jands Event Plus Operating Manual

Creating Memories & Chases
50 Event V3 Manual
8.92 METHOD 2: Using Assign Flash Buttons
Diagram 8K
Press the Edit button.
1
Press the Flash button beneath the Assign fader controlling the item to be
2
edited.
Use the Preset 1 (top preset) faders to set new levels for the channels you
3
want to change. To edit a channel this way the fader first has to be moved
to match the existing level of the channel and then moved to the new level.
The simplest way to do this is to move the fader from zero to full and then
to the new level.
TIP:
Finding the Step to edit
If you want to edit a particular Step of the Chase but are not sure of the Step
number there is an easy solution. First bring the Chase up on one of the Assign
Masters, then use the rotary speed control to slow the chase right down until it
stops. Now use the Assign Flash button to single step the Chase to the Step you
want. Finally, press the Edit button followed by the Chase Flash button and the
edit Chase menu will open with the Step you want to edit already selected.
NOTE:
As each channel or group of channels is adjusted using either edit method, the
changes are stored temporarily so there is no need to press Record to save each
individual change.
4 Press the Record button. The LCD will display the percentage of available
Memory space that has been used and that which remains, and return to the
standard screen after the button is released.
NOTE:
Whenever the EDIT CHASE menu is opened the Preset faders are disabled from
outputting to the stage. However, they can be used to set levels for the item being
edited.
