JANDS – Event 4 Version 5 Users Manual
16.1.3

To Change the Operation of the Chase Flash Button

16.2 Controlling Stacks

To control a Stack you use either a single or two adjacent Assign Masters. To get the
Stack onto these Masters you can use two different Methods. The best Method to use
will depend on the type of show that you are running, as explained below:
16.2.1

Method 1: Using the Assign Stack Menu

This Method is best if you are only using a Stack occasionally or for a specific part of
a show.
16.2.2

Method 2: Using the Stack Menu

If you want to have a Stack available all the time it is best to use the Stack menu to
dedicate a fader (or fader pair) to Stack playback.
Press Stack button to display the menu
Type
First
Assign
Mask
Load
Page 58
1. Press the Setup button to open the Setup Menu.
2. Move the cursor to the Ctrl (Controls) field and press the + (On) button to
open the Set Control menu.
3. Move the cursor to the CHS field and press the + (On) button to toggle
between Norm (Normal) and Sngl (Single).
4. Press Exit to close this menu.
1. Press Assign then Stack to open the Assign Stack menu
2. Set the first memory or chase to playback.
3. Press an Assign master flash button to put the Stack on that fader
Type First
Std M 10.00
This field can be set to either Std, MTC or Prog.
Std is the default setting and most commonly used.
MTC is for playback using Midi Time Code.
Prog is for playback using Midi Programme messages.
Sets the first memory (or Chase) number.
Sets the Assign Fader/s used to control the stack playback.
Sets any or all of Intensity, Focus, Colour and Beam to be masked during
playback. Masked parameters are recorded but ignored during playback.
Any letter (IFCB) shown indicates that the parameter will be masked. eg.
if the display shows I-BF only the colour information will play back. All
other parameters will remain under the previous control.
Turns the Stack On or Off. When this field is changed to On (or Off), the
menu is automatically closed.
Revision 5.0.0.5
Assign Load Mask
1 Off Off
25/11/02
