Lablling A Chase - Jands Event Plus Operating Manual

Creating Memories & Chases
38 Event V3 Manual
8.20 Labelling a Chase
Diagram 8B + 8A
Chases can be labelled to allow easy identification of their contents. For example,
Chases might be labelled FAST or SLOW and then whenever those Chases are
loaded to the Assign Masters the label is displayed in the LCD window above the
fader. Chases can be labelled while they are being recorded or at a later time.
1. Move the cursor to the Label field (to the right of the Chase number field).
2. Type a label of up to eight characters using the Flash buttons.
3. Press the Exit button if no more Chases are to be labelled.
NOTE:
Do NOT press the Record button if only entering or changing a label.
_
C
A 1
PRESET PRESET PRESET ASSIGN ASSIGN ASSIGN
FLASH FLASH FLASH FLASH FLASH FLASH
OR
7 8 9
MEMORY EDIT CHASE
4 5 6
PAGE ASSIGN FILE
__ _ 1 2 3
BUILD CLEAR STACK
1
0
EXIT SETUP RECORD
OR
8B Labelling a Chase
7 8 9
MEMORY EDIT CHASE
5 6
4
PAGE ASSIGN FILE
1 2 3
BUILD CLEAR STACK
0
EXIT
SETUP RECORD
Press Exit
if only
entering
a label
x x x x
x x x x
