Jands Event Plus Operating Manual page 14

General Description
PRESET PRESET
FLASH FLASH
3F Preset Flash button
ASSIGN ASSIGN
FLASH FLASH
3G Assign Flash button
_ __ _
M E : M I n f a d e O
M 1 0 M 1 0 0 : 0 0 0 0
3H Memory Menu
7 8 9
MEMORY EDIT CHASE
4 5 6
PAGE ASSIGN FILE
1 2 3
BUILD CLEAR STACK
0
EXIT
SETUP RECORD
3I Exit button
7 8 9
CHASE
MEMORY EDIT
5
4 6
PAGE ASSIGN FILE
1 2 3
BUILD CLEAR STACK
0
RECORD
EXIT SETUP
3J Record button
14 Event V3 Manual
3.40 Entering Numbers Directly to Fields
Once a menu has been opened the function buttons change to a numeric keypad.
Numbers can be entered directly into menu fields such as Page number, Memory
number and so on.
3.50 Entering Labels
Diagram 3F, 3G, 3H
The Memory, Chase, Page, File and Patch menus all have a Label field. The section
circled in Diagram 3H shows the Memory menu with the Label field highlighted
(the other menus all have the Label field in the same position). The Event
automatically supplies a label for each field (in the diagram shown as M10) but the
Preset/Assign Flash buttons can be used to type a label of your choice. Below each
Flash button there is a character marking.
Example:
•
•
u t f d e
: 0 0 0 Mo e r
3.60 Exit Button
The Exit button is used to back out of the menu system. If a top level menu is open,
pressing Exit closes the menu system. If a nested menu is open pressing the Exit
button makes the display return to the previous (higher level) menu.
If no menu is open the Exit button can be used to show the Event software version
number.
3.70 Record Button
When a menu is open the Record button is used to save new or modified intensity
settings.
If no menu is open the Record button can be used to change the LCD window from
showing Memory and Chase labels to showing Memory and Chase numbers. This
feature is useful if you have given names to Memories and Chases and need to know
what number they were, or need to see the steps of a Chase sequencing.
Open the Memory menu and use the right arrow button to move the cursor
to the first character position of the label field.
Type BLUE WASH or something similar. If you make a mistake just use the
cursor buttons to move back and type over the incorrect character. The
square box marking below the third (fifth on Event Plus) Assign Master
Flash button represents a space. You can also use the numeric keypad
to type numbers.
Diagram 3I
Diagram 3J
