Jands Event 4 Technical Manual

Hide thumbs Also See for Event 4:
Table of Contents

Advertisement

Quick Links

Event 4 Technical Manual
Revision 1
19/07/99

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Event 4 and is the answer not in the manual?

Questions and answers

Related Manuals for Jands Event 4

Summary of Contents for Jands Event 4

  • Page 1 Event 4 Technical Manual Revision 1 19/07/99...
  • Page 2 It is recommended that all service and repairs on this product be carried out by JANDS ELECTRONICS P/L or it’s authorised service agents. JANDS ELECTRONICS P/L cannot accept any liability whatsoever for any loss or damage caused by service, maintenance or repair by unauthorised personnel, or by use other than that intended by the manufacturer.

  • Page 3: Table Of Contents

    5. Boot ROM inbuilt menu, self tests, setups, etc ....5-1 5.1 Entering the Boot Menu ..................... 5-1 5.2 Menu Usage ....................... 5-1 5.3 Boot Menu........................5-1 5.3.1 Continue ...................... 5-1 5.3.2 Reload Software..................5-1 5.3.3 Test......................5-2 CPU........................5-2 Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 4 Trash RAM ......................5-6 Boot........................5-6 6. Fault Finding Table..............6-1 7. Maintenance................7-1 8. Technical Data and Specifications ........8-1 Event 4 Specifications Glossary of Terms ...............9-1 Appendix A: History of Modifications ........9-1 Appendix B: Connector Pinouts ..........9-1 Appendix C: Spare Parts............9-1 Appendix D: DMX to MIDI adaptor..........9-1...
  • Page 5 Contents EV4CPU1 Circuit diagrams ............9-2 EV4MAST3 Circuit diagrams............9-3 EV4ASN3 Circuit diagrams ............9-4 EV4PRE3 Circuit diagrams ............9-5 EV4PAL3 Circuit diagrams............9-6 BKLTSML0 Circuit diagrams .............9-7 Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 6: Introduction

    1 - 1 1. Introduction The Event 4 lighting control console is designed for stage, theatre, corporate, and live music applications. It has been designed to control all equipment with a DMX-512 input. New fixture types can be added by modifying the fixture library disk if they are not available on the existing release library.

  • Page 7: Equipment Description

    3 - 1 2. Equipment Description The Event 4 is constructed using a folded steel chassis, covered with a reverse screened lexan. The decorative wooden ends are made from plantation growth native Australian timber mounted on an aluminium former, which provides structural rigidity.

  • Page 8: Reassembly

    • Do not overtighten the base screws. 2.4 Precautions and Installation Notes The Event 4 should be installed in a position which allows sufficient ventilation around the back panel vents – there should be at least 100mm clear space around the back panel.

  • Page 9: Circuit Notes

    Circuit Notes 3 - 1 3. Circuit Notes The Event 4 uses a main CPU to provide all processing functions. The CPU communicates with the front panel PCBs via the front panel card bus. 3.1 Processor Card The major functional blocks are as follows:...

  • Page 10: Battery

    After a fault has been removed this device takes approximately one minute to reset, and during this time the keyboard should be disconnected or the console switched off. Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 11: Expansion Bus

    3.2 Front Panel Cards All front panel cards follow a design similar to that of other Jands consoles. A multiplexed 8 bit data/address bus is used to exchange bytes of information between the CPU and the front panel cards. The pin connections however are not compatible and under no circumstances should Event, ESP2, and Jandshog type front panel circuit boards ever be connected to an Event 4 CPU card.

  • Page 12: Dip Switch Settings

    Dip SW4 - no function Dip SW5 - no function Dip SW6 - Enable main code diagnostics Dip SW7 - Execute software from RAM – use for development only Dip SW8 - Reserved Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 13: Boot Rom Inbuilt Menu, Self Tests, Setups, Etc

    Selecting the Load FLASH option initiates the software reload sequence from diskette. Ensure you have an Event 4 software diskette with the file “EVENT4.BIN in the drive and follow the instructions on the LCD. Note that this facility should be used with caution and it is not recommended that software be reloaded at a critical time, eg.

  • Page 14: Test

    IC13 pin 29 Write to FLASH byte 0 Move 20 to 20000001 IC14 pin 29 Write to FLASH byte 1 Move 40 to 20000002 IC12 pin 29 Write to FLASH byte 2 Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 15 Figure 1: Sample waveform during Bus Exercise Trace #1: Trace #2: IC16 Pin 29 (WR) Trace #3: IC1 pin 44 (DACK1) Trace #4: IC1 pin 43 (DACK0) Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 16: Ram

    Appendix D, or the combiner circuit shown in Appendix E. When the test is run the DMX2 output is exercised and the results read back into the MIDI input. The test takes about 3 seconds to complete. Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 17: Midi

    Associated LED turns from green to red Master Buttons with no LED Master Wheels Master Faders Preset Faders Associated Mimic LEDs Preset Flash Buttons Associated Mimic LEDs Table z: Front panel activation responses Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 18: Misc

    The console is restarted. This is generally used when use of the self tests has been completed and it is desired to start the main operating software. Holding the Enter button down immediately after activating this option allows re-entry to the self tests and setups. Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 19: Fault Finding Table

    Power fail circuit out of adjustment Re-trim T1 as per section 3.1.2 Console always shows error Software bug Write down message and forward to Jands, then RAM trash as described in section 5.3.3.4.3 Console won’t write or read diskette Disk not DOS format Format compatible computer (DOS 3.0 and above)

  • Page 20: Maintenance

    Use only a damp soft cloth for cleaning. The console operating software is extremely complex. It is recommended that the console be deep cleared at the start of each new tour. Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 21: Technical Data And Specifications

    Technical Data and Specifications 8. Technical Data and Specifications Event 4 Specifications Mains Supply: 90-265VAC, 47-63Hz, 60 watts max. Mains Fuse: 2A, M205 delay type Temperature: 40°C maximum ambient Outputs: DMX Out 1 & 2, MIDI Thru, MIDI Out, Two Desk Lamps, VGA...

  • Page 22: Glossary Of Terms

    A diode that is optimised to radiate light Diode Liquid Crystal A type of display that uses a liquid to prevent the Display transmission of light Non-Maskable An IRQ that cannot be ignored Interrupt Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 23 A miniaturised leadless component mounted on Device the upper or lower surface of a circuit board SRAM Static RAM A form of RAM that uses static memory cells to store information. Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 24: Appendix A: History Of Modifications

    Appendix A – History of Modifications A - 1 Appendix A: History of Modifications Serial Number Modification Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 25: Appendix B: Connector Pinouts

    Appendix B - Connector Pinouts B - 1 Appendix B: Connector Pinouts Front Panel Card Bus Connector (View from component side) Palette, Assign, Master Cards FDD Power Connector Main Power Connector (CONN8) -12V +12V Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 26 FDD Connector (CONN6) Expansion bus Connector (CONN2) DSKCHG HDSEL +12v RDATA -12V WRTPRT TRK0 WGATE WDATA STEP MTR1 MTR0 INDEX DRATE1 DENSEL RESET DMX CONNECTOR (Conn19) DMX1+ DMX1- DMX2- DMX2+ Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 27 DESK LAMP CONNECTIONS PIN No. FUNCTION DESK LAMP CONNECTOR MIDI CONNECTIONS FUNCTION THRU SHIELD SHIELD OUT+ OUT+ OUT- OUT- MIDI CONNECTOR KEYBOARD CONNECTIONS PIN No. FUNCTION KCLK KDATA KEYBOARD CONNECTOR Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 28 B - 4 DMX CONNECTIONS PIN No. FUNCTION SHIELD SIGNAL- SIGNAL+ DMX CONNECTOR VGA CONNECTIONS PIN No. FUNCTION GREEN BLUE RED RETURN GREEN RETURN BLUE RETURN HSYNC VSYNC VGA CONNECTOR Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 29: Appendix C: Spare Parts

    Appendix C - Spare Parts C - 1 Appendix C: Spare Parts The following spare parts for Event 4 consoles are available from the JANDS Service Department: ITEM PART No. Switching power supply NFS40-7608 ZSX0200 Fuse M205 2 amp fast blow (mains) ZEF2150 3.5”...
  • Page 30 Appendix C - Spare Parts C - 2 Assign card complete YPC175 Master card complete YPC176 CPU card complete YPC174 Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 31: Appendix D: Dmx To Midi Adaptor

    From DMX1 output From Keyboard Input 100nF To MIDI Input IC3B 220R 74HC10 IC3A 75176 74HC10 220R From DMX2 output IC3C 74HC10 270R OPTO1 From MIDI output H11N1 220R 1N914 Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 32: Appendix F: Circuit Diagrams

    Circuit Diagrams and Overlays F - 1 Appendix F: Circuit diagrams Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 33: Ev4Cpu1 Circuit Diagrams

    Circuit Diagrams and Overlays F - 2 EV4CPU1 Circuit diagrams Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 37: Ev4Mast3 Circuit Diagrams

    Circuit Diagrams and Overlays F - 3 EV4MAST3 Circuit diagrams Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 40: Ev4Asn3 Circuit Diagrams

    Circuit Diagrams and Overlays F - 4 EV4ASN3 Circuit diagrams Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 42: Mascot Nsw

    SERU SERU SERU L(1..8) SERU1 SERU1 SERU1 SERU1 SERU1 SERU1 SERU1 SERU1 LL(1..8) Title Jands Electronics P/L 40 Kent Rd EVENT4 ASSIGN CARD Mascot NSW 2020 Australia Ph (02) 9582-0909 EV4ASN3 Size: Number: Revision: File: Date: 9-Jul-1999 Sheet Drawn By:...

  • Page 43: Ev4Pre3 Circuit Diagrams

    Circuit Diagrams and Overlays F - 5 EV4PRE3 Circuit diagrams Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...

  • Page 46: Ev4Pal3 Circuit Diagrams

    Circuit Diagrams and Overlays F - 6 EV4PAL3 Circuit diagrams Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 48 Circuit Diagrams and Overlays F - 7 BKLTSML2 Circuit diagrams Revision 1 - 07 July 1999 Event 4 TECHNICAL MANUAL...
  • Page 49 100R TO BACKLIGHT 100-300VAC Output 1 10uF Output 2 BCX17 BCX19 Seiko 5C 220R INV1 10uF Title Jands Electronics P/L 40 Kent Rd Small Backlight driver Mascot NSW 2020 Australia bkltsml0 Size: Number: Revision: Ph (02) 9582-0909 File: Date: 9-Jul-1999...
