Control Functions - Playback
94 Event V3 Manual

13.92 SMaster as Assign Faders Master

1. Check that the ASSIGN LED is lit.
2. The SMaster fader scales the intensity of the Assign Master faders.
Example: (Grand Master at 100%)
Assign Master 1 includes Channel 1 at 90%, Assign fader 1 is set to 80%
and the SMaster is set to 50%. The resultant intensity of the output from
channel 1 is 36%:
0.9 x 0.8 x 0.5 = 0.36 (36%)

13.93 SMaster as Hold Master

The Hold function is used to control the console output while changing Pages or to
store a special look that is used at the end of each song.
1. Check that the Hold LED is lit. If the LED in the Sample button is lit, press
the button to clear it.
2. Set up a console output using the Preset (or Assign) faders.
3. Press the Sample button. This takes a "snapshot" of the console output and
the LED in the Sample button lights.
4. Fade the Preset and Assign faders to 0.
5. Grand Master at 100%.
6. The SMaster fader can now be used to fade the "snapshot" up and down.

13.94 SMaster as Manual Crossfade Master

Use manual crossfades to achieve a smooth transition between any Memories
currently on the Assign faders
1. Check that the SMAST field in the Setup Control menu is set to XFADE.
Check that the fader is at zero.
2. Press and hold the button above the SMaster fader.
3. Press the Flash button beneath any of the Assign faders.
4. Release both buttons.
5. Move the SMaster fader up to fade in the chosen Memory.
6. Repeat steps 2 ~ 4 to chose another Memory.
7. Move the SMaster fader down to perform a dipless crossfade between the
two Memories.

13.95 SMaster as Memory / Chase Control

Use the SMaster as an extra Assign Master when all other Assign Masters are
occupied.
1. Check that the SMAST field in the Setup Control menu is set to MEM /CH.
2. Press the Assign button followed by the Memory or Chase button.
3. Select a Memory or Chase number.
4. Press the button above the SMaster fader.
5. The SMaster controls now control that Memory / Chase in the same way as
the Assign faders.
