Lcd Windows; Controlling Memories; Assign Masters; Controlling Chases - Jands Event Plus Operating Manual

13C LCD display
* Solo: The Memory goes to the level set by the Add / Solo Master and at the same
time blacks out the other console controls.
* Latch: Press once to switch the Memory on at the level set by the Add / Solo
Master. Press again to switch the Memory off.
TIP:
Timed Fades
If you have set an Infade time, the Memory will fade in over that time whenever
the Flash button is pressed. Likewise, if you have set an Outfade time, the
Memory will fade out over that time when the Flash button is released.

13.14 LCD Windows

Diagram 13C
The windows above the Assign Master faders show the Memory number or name
(to add a name at any time use the Memory menu see Section 7.00).
TIP:
If you have given a Memory a name and want to know what number it is, hold down
the Record button. The LCD will then change to show the number of each item on
the display.

13.20 Controlling Memories

Once a Memory has been assigned to a fader or loaded as part of a Page or File it
is ready for use.

13.21 Assign Masters

2
Diagram 13B
The Assign Master fader is used to scale the intensity of the Memory from 0% to
100%.
13.22 LCD Windows
Diagram 13C
The Memory number or name, if one is used, will appear in the LCD window above
the fader (to add a name at any time use the Memory menu see Section 7.00).
TIP:
If you have given a Memory a name and want to know what it is, hold down
the Record button. The LCD will then change to show the label of each item on
the display.

13.30 Controlling Chases

Chases are controlled in much the same way as Memories.
13.31 Assign Masters
2
Diagram 13B
The Assign Master fader is used to scale the intensity of the Chase from 0% to 100%.
© Jands Electronics July 1995
Event V3 Manual 87
