8. Technical references
Parameter
Position (for each sensor)
Rotation (for each sensor)
Inclination (for each sensor)
Sensor installation height (for each sensor) 0 mm
Detection Distance 1(for each sensor)
Detection Distance 2, 3 and 4 (for each
sensor)
Angular coverage
Safety working mode (for each detection
field of each sensor)
Static object detection (for each detection
field of each sensor)
Restart timeout (for each detection field of
each sensor)
T
OFF
Detection field dependency
Anti-masking
Anti-masking distance
Anti-rotation around axes
Anti-rotation around axes - Enable specific
axes - Tilt
Anti-rotation around axes - Enable specific
axes -Roll
Anti-rotation around axes - Enable specific
axes - Pan
Digital input (for each input)
Digital output (for each output)
OSSD Pulse width
Group for muting (for each sensor)
Pulse width (for each Input TYPE)
Period (for each Input TYPE)
Phase shift (for each Input TYPE)
Detection field 1, 2, 3, 4
92
Min
X: 0 mm
Y: 0 mm
0°
-90°
0 mm
0 mm
10°
Both (default), Always access detection,
Always restart prevention
Enabled, Disabled
100 ms
100 ms
Settings > Sensors
Enabled, Disabled
Disabled, Low, Medium, High
0 mm
Disabled, Enabled
Disabled, Enabled
Disabled, Enabled
Disabled, Enabled
Settings > Digital Input-Output
Stop signal, Restart signal, Muting group
"N", Activate dynamic configuration,
Fieldbus controlled
System diagnostic signal, Muting enable
feedback signal, Fieldbus controlled,
Restart Feedback signal, Detection signal
"N"
Short (300 μs), Long (2 ms)
Settings > Muting
None, Group 1, Group 2, both
0 μs (= Period and
Phase shift disabled)
200 μs
200 ms
0.4 ms
Settings > Restart parameters
Automatic, Manual, Safe manual
SBV System Series | Instruction manual v1.2 DEC 2021 | SAF-UM-SBVBus-en-v1.2 | © 2021 Inxpect SpA
Max Default value
X: 65000 mm Default position of
sensor #1:
Y: 65000 mm
X: 1000 mm
Y: 1000 mm
359° 0°
90° 0°
10000 mm 0 mm
5000 mm 1000 mm
5000 mm 0 mm
Note: the sum of all
the detection
distances (for each
sensor) must not
exceed 5000 mm.
100° 100°
Both (default)
Disabled
60000 ms 4000 ms
60000 ms 100 ms
Enabled
High
1000 mm 1000 mm
Enabled
Enabled
Enabled
Enabled
Not configured
Not configured
Short (300 μs)
Group 1
2000 μs 0 μs
2000 ms 200 ms
1000 ms 0.4 ms
Automatic
