2.1.5 INTENDED USE
SBV System Series is certified SIL 2 according to IEC/EN 62061, PL d according to EN ISO 13849-1 and
Performance Class D according to IEC/TS 62998-1.
It performs the following safety functions:
Access detection function: access to a hazardous area deactivates the safety outputs to stop the moving
l
parts of the machinery.
Restart prevention function: prevents unexpected starting or restarting of the machinery. Detection of
l
motion within the dangerous area maintains the safety outputs deactivated to prevent machinery starting.
It performs the following optional safety functions:
Stop signal: force all the safety outputs to OFF-state.
l
Restart signal: enables the control unit to switch to ON-state the safety outputs related to all the detection
l
fields with no motion detected.
Muting (see "Muting" on page 37).
l
SBV System Series is suitable for protecting the entire body for the following applications:
dangerous area protection
l
mobile dangerous area protection
l
indoor and outdoor applications
l
SBV System Series meets requirements of applications safety functions that require a risk reduction level of:
Up to SIL 2, HFT = 0 according to IEC/EN 62061
l
Up to PL d, Category 3 according to EN ISO 13849-1
l
Up to Performance Class D according to IEC/TS 62998-1
l
SBV System Series, in combination with additional risk reduction means, can be used for applications safety
functions that require higher risk reduction levels.
The following is deemed improper use in particular:
Any component, technical or electrical modification to the product,
l
Use of the product outside the areas described in this document,
l
Use of the product outside the technical details, see "Technical data" on page 79.
l
2.1.6 EMC-COMPLIANT ELECTRICAL INSTALLATION
NOTICE: The product is designed for use in an industrial environment. The product may cause interference if
installed in other environments. If installed in other environments, measures should be taken to comply with the
applicable standards and directives for the respective installation site with regard to interference.
2.1.7 GENERAL WARNINGS
Incorrect installation and configuration of the system decreases or inhibits the protective function of the
l
system. Follow the instructions provided in this manual for correct installation, configuration and validation of
the system.
Changes to the system configuration may compromise the protective function of the system. After any
l
changes made to the configuration, validate correct functioning of the system by following the instructions
provided in this manual.
If the system configuration allows access to the dangerous area without detection, implement additional
l
safety measures (e.g. guards).
The presence of static objects, in particular metallic objects, within the field of view may limit the efficiency of
l
sensor detection. Keep the sensor field of view unobstructed.
The system protection level (SIL 2, PL d) must be compatible with the requirements set forth in the risk
l
assessment.
Check that the temperature of the areas where the system is stored and installed is compatible with the
l
storage and operating temperatures indicated in the technical data of this manual.
Radiation from this device does not interfere with pacemakers or other medical devices.
l
