Inxpect SBV System Series Instruction Manual page 65

LED Status
S6 Steady red FEE ERROR, FLASH
S1–S6 Steady red FIELDBUS ERROR
together
S1–S5 Steady red DYNAMIC
together
S1–S4 Steady red SENSOR
together
At least Flashing
one LED red
At least Flashing
one LED green
All the Steady
LEDs orange
All the Flashing
LEDs green one
after the
other in
sequence
Note: fault signal on the control unit (steady LED) takes priority over a faulty sensor signal. For the status of the
single sensor, check the sensor LED.
Note*: S1 is the first from the top.
Note**: S1 corresponds to the sensor with ID 1, S2 corresponds to the sensor with ID 2 and so on.
7.1.2 Sensor LED
Inxpect Safety application
Status
Steady -
purple
Flashing -
purple *
Flashing CAN ERROR
red. Two
flashes
followed by
a pause **
Flashing CAN ERROR
red. Three
flashes
followed by
a pause **
SBV System Series | Instruction manual v1.2 DEC 2021| SAF-UM-SBVBus-en-v1.2 | © 2021 Inxpect SpA
Inxpect Safety
application messages
ERROR or RAM ERROR
CONFIGURATION ERROR
CONFIGURATION ERROR
"Sensor LED" on the next
page
"Sensor LED" on the next
page
-
messages
Problem
Configuration saving
error, configuration not
performed or memory
error
Communication error
on the Fieldbus
Error in the selection of
the dynamic
configuration: invalid
ID
Error during the
configuration of the
sensors
Sensor corresponding
to the flashing LED in
error ** ("Sensor LED"
on the next page)
Sensor corresponding
to the flashing LED in
error ** ("Sensor LED"
on the next page)
The system is starting
up.
The control unit is in
boot state.
Problem
Sensor in boot state
Sensor receiving a
firmware update
Sensor without a valid
identifier assigned
Sensor does not receive
valid messages from
the control unit
7. Maintenance and troubleshooting
Remedy
Reconfigure or configure the
system, see "Manage the
configuration" on page 61.
If the error persists, please contact
assistance service.
At least one input or output is
configured as Fieldbus controlled.
Check that the cable is correctly
connected, communication with the
host is correctly established and the
exchanged data are maintained
passivated by the host itself.
Check the preset configurations
within the Inxpect Safety
application.
Check the sensors connected and
try again to perform the
configuration of the system via the
Inxpect Safety application.
Check the problem through the LED
on the sensor.
If the issue persists longer than one
minute, please contact assistance
service.
Wait for a few seconds.
Please contact assistance service.
Remedy
Perform a sensor firmware update or
contact technical support.
Wait for the update to be completed
without disconnecting the sensor.
Assign a Node ID to the sensor, see
"Connect the control unit to the
sensors" on page 57.
Verify the connection of all sensors in
the chain since the last sensor in error
