Inxpect SBV System Series Instruction Manual page 72

7. Maintenance and troubleshooting
distance (in mm) and the detection angle (°). See "Verbosity level for detection access and exit events" on
page 70
Format: Detection access (field #n, distance mm/azimuth°)
Example:
20 2020/11/18 16:47:25
7.3.7 Detection exit
After at least one detection access event, a detection exit event related to the same field is logged when the
detection signal returns to its default no-motion status.
Depending on the selected verbosity level additional parameters are logged: the detection field number, the
sensor which detected the motion.
Format: Detection exit (field #n)
Example:
20 2020/11/18 16:47:25
7.3.8 Dynamic configuration in use
At every change of the dynamic configuration, the new ID of the dynamic configuration selected is logged.
Format: Dynamic configuration #1
Example:
20 2020/11/18 16:47:25
7.3.9 Muting status
Every change of the muting status of each sensor is logged as disabled or enabled.
Note: the event indicates a change of the muting status of the system. It does not correspond to the muting
request.
Format: Muting disabled/enabled
Example:
20 2020/11/18 16:47:25
7.3.10 Fieldbus connection
The Fieldbus communication status is logged as CONNECTED, DISCONNECTED or FAULT.
Format: Fieldbus connection CONNECTED/DISCONNECTED/FAULT
Example:
20 2020/11/18 16:47:25
7.3.11 Modbus connection
The Modbus communication status is logged as CONNECTED or DISCONNECTED.
Format: Modbus connection CONNECTED/DISCONNECTED
Example:
20 2020/11/18 16:47:25
72
[INFO] SENSOR #1 Detection access (field #1, 1200 mm/30°)
[INFO] CONTROL UNIT
[INFO] CONTROL UNIT
[INFO] SENSOR#1 Muting enabled
[INFO] CONTROL UNIT
[INFO] CONTROL UNIT
SBV System Series | Instruction manual v1.2 DEC 2021 | SAF-UM-SBVBus-en-v1.2 | © 2021 Inxpect SpA
Detection exit (field #1)
Dynamic configuration #1
Fieldbus connection CONNECTED
Modbus connection CONNECTED
