8.3.8 Diagnostic output connection
Note: the indicated light turns on in the presence of a failure.
Digital I/O settings (through the Inxpect Safety application)
Digital input #1 Not configured
Digital input #2 Not configured
Digital output #1 Not configured
Digital output #2 Not configured
Digital output #3 Not configured
Digital output #4 System diagnostic signal

8.4 Parameters

8.4.1 Parameter list
Parameter
Password
Country
Application type selection
Number of installed sensors
Plane
SBV System Series | Instruction manual v1.2 DEC 2021| SAF-UM-SBVBus-en-v1.2 | © 2021 Inxpect SpA
Min Max
Settings > Account
- -
Settings > General
Europe, Rest of the world or list of countries Europe, Rest of the
Fixed, Vehicle mount
Configuration
1 6
Dim. X: 1000 mm Dim. X: 65000 mm
Dim. Y: 1000 mm Dim. Y: 65000 mm
8. Technical references
Default value
Not available
world
Fixed
1
Dim. X: 8000 mm
Dim. Y: 6000 mm
91
