Inxpect SBV System Series Instruction Manual page 74

7. Maintenance and troubleshooting
Screen printing
V12 sensors
VUSB
VREF
ADC
7.4.4 Peripheral error (PERIPHERAL ERROR)
Error detected by diagnostics relative to the micro-controller, its internal peripherals or memories.
7.4.5 Configuration errors (FEE ERROR)
Indicates that the system must still be configured. This message can appear when the system is first turned on or
after reset to default values. It can also represent another error on the FEE (internal memory).
7.4.6 Output errors (OSSD ERROR)
Error
OSSD 1 SHORT
CIRCUIT
OSSD 2 SHORT
CIRCUIT
OSSD 3 SHORT
CIRCUIT
OSSD 4 SHORT
CIRCUIT
OSSD 1 NO LOAD
OSSD 2 NO LOAD
OSSD 3 NO LOAD
OSSD 4 NO LOAD
OSSD 1-2 CROSS
CHECK
OSSD 1-3 CROSS
CHECK
OSSD 1-4 CROSS
CHECK
OSSD 2-3 CROSS
CHECK
OSSD 2-4 CROSS
CHECK
OSSD 3-4 CROSS
CHECK
7.4.7 Flash errors (FLASH ERROR)
A flash error represents an error on the external flash.
7.4.8 Dynamic configuration error (DYNAMIC CONFIGURATION ERROR)
A dynamic configuration error indicates an invalid dynamic configuration ID.
7.4.9 Internal communication error (INTERNAL COMMUNICATION ERROR)
Indicates that there is an internal communication error.
74
Sensors power supply voltage
USB port voltage
Inputs reference voltage (VSNS Error)
Analog-digital converter
Short-circuit error on MOS output 1
Short-circuit error on MOS output 2
Short-circuit error on MOS output 3
Short-circuit error on MOS output 4
No load detected on MOS output 1
No load detected on MOS output 2
No load detected on MOS output 3
No load detected on MOS output 4
Short-circuit error between MOS output 1 and 2
Short-circuit error between MOS output 1 and 3
Short-circuit error between MOS output 1 and 4
Short-circuit error between MOS output 2 and 3
Short-circuit error between MOS output 2 and 4
Short-circuit error between MOS output 3 and 4
