Symbols

These symbols can appear on the cableless measurement devices and associated equipment.
Symbols
Caution, consult
accompanying
documents
Equipotential grounding
Error LED
Non-ionizing radiation
symbol
Always use separate
collection for waste
electrical and electronic
equipment (WEEE)
Indicates location of
serial number
Followed by two
alphanumeric characters,
indicates ingress
protection grade

Installation Safety Information

Grounding
Equipotential Grounding
Combining Equipment
Fusing
Refer to accompanying
documents
Alternating current
Built-in wireless network
(WLAN)
NBP identifier
Identifies year and
month of manufacture
Indicates location of
catalog number
LAN connection
indicator for connection
to a wired network
The charging station must be grounded during operation. If a three-wire receptacle
is not available, consult the hospital electrician. Never use a three-wire to two-wire
adapter.
If the charging station is used in an OR, ensure that the room incorporates an
equipotential grounding system to which the charger has a connection.
Combinations of medical equipment with non-medical equipment must comply
with IEC 60601-1-1. Never use a multiple portable socket-outlet or extension cord
when combining equipment unless the socket outlet is supplied specifically for use
with that equipment.
The charging station uses double pole/neutral fusing.
10 Specifications
Protective earth
Connector has special
protection against electric
shocks and is defibrillator
proof
USB interface
SpO identifier
2
Indicates location of the
date of manufacture and/
or name and address of
manufacturer
Indicates location of
service number
