10 Specifications
Performance Specifications
Short Range Radio Specifications
Type
Technology
Frequency band
Modulation
Bandwidth
Effective radiated power (ERP)
IntelliVue CL Transmitter Specifications
Physical Specifications
Size (W X H X D)
Weight
Robustness
Ingress Protection
Environmental Specifications
Operating Temperature Range
Operating Humidity Range
Operating Altitude Range
Storage / Transportation Temperature
Range
Storage / Transportation Humidity
Range
Storage / Transportation Altitude Range -500 to 4600m
78
built in interface with integrated antenna
IEEE 802.15.4
2.4 GHz ISM (2.400 - 2.483 GHz)
DSSS (O-QPSK)
5 MHz
max. 0 dBm (1 mW)
55 mm x 26.5 mm x 122 mm ±5%
2.2 in x 1.0 in x 4.8 in ±5%
(without cradle)
150 g ±10%
5.8 oz ±10%
(without cradle)
Provides essential performance during exposure to random vibration
according to IEC TR 60721-4-7 Class 7M1
Survives shock, random vibration and bump according to IEC TR 60721-4-
7 Class 7M3 as well as a 1 m drop
IP32 according to IEC 60529 (protected against ingress of water when the
water is dripping vertically and the CL Transmitter is tilted up to 15° and
protected against contact with or ingress of objects larger than 2.5 mm)
0 to 40°C (32 to 104°F)
0 to 35°C (32 to 95°F) when charging the battery with an active WLAN
connection
≤95% RH @ 40°C (104°F)
no condensation
-500 to 3000m
-20 to 60°C (-4 to 140°F)
≤90% RH @ 60°C (140°F)
(non-condensing)
