requirements regarding electrical installation according to IEC 60364-7-710 "Requirements for special
installations or locations - Medical locations", or corresponding local regulations.
Physical Specifications
Size (W X H X D)
Weight
Robustness
Environmental Specifications
Operating Temperature Range
Operating Humidity Range
Operating Altitude Range
Storage/Transportation Temperature
Range
Storage/Transportation Humidity
Range
Storage/Transportation Altitude Range -500 to 4600 m
Performance Specifications
Display Specifications
Type
Viewing Area
Dot Size
Resolution
Backlight
Sounds
Charging Current (all slots)
Charging Current (one slot)
Mains Power
USB Downstream
USB Upstream
343 mm x 117 mm x 172 mm ±5%
13.5 in x 4.6 in x 6.8 in ±5%
2000 g ±10%
4.4 lb ±10%
Operating within specification during exposure to random vibration
according to IEC TR 60721-4-7 Class 7M1
Survives shock and 0.05 m free fall according to IEC TR 60721-4-7 Class
7M1
0 to 35°C (32 to 95°F)
A temperature-controlled fan becomes active at operating temperatures
above 30°C (typical)
≤95% RH @ 40°C (104°F)
-500 to 3000 m
-20 to 60°C (-4 to 140°F)
≤90% RH @ 60°C (140°F)
no condensation
monochrome (4 gray scales), passive LCD (STN), positive/transflective
25.6 mm x 19.2 mm
0.2 mm x 0.2 mm
128 x 96 pixel
white LED
Hardkey operation tone
max. 4.8A (24W @5V)
max. 2A (10W @ 5V)
50/60 Hz; 1.3 - 0.7A; 100 - 240V~
Standard: USB 2.0 low/full speed Host Port
Power Output: 5V ± 5%, 500 mA max
Connector: USB series "Standard-A" receptacle
Standard: USB 2.0 full speed Device Port
Power input: "self powered device"
Connector: USB series "Standard-B" receptacle
10 Specifications
