1 Introduction and Basic Operation
Measurement Device Main Parts and Keys
All IntelliVue Cableless Measurement devices have a display and 3 keys:
Operating and Navigating
The following sections describe operation on the IntelliVue Cableless Measurement device itself. For
operation from a patient monitor, see "Controls Available with a Patient Monitor" on page 27. For
operation from an Information Center via a telemetry system, see "Controls Available With a
Telemetry Device" on page 28.
The IntelliVue CL Cableless Measurement devices have three hardkeys for basic operation and a set of
configurable SmartKeys which appear on the screen. These are used to navigate through the screen
elements and activate the on-screen menus for the individual items.
Switching the Devices On
The first time an IntelliVue Cableless Measurement Device is used, or after a device has been powered
off for storage, place it on the IntelliVue CL Charging Station. This will automatically switch the device
on.
If the device has only been switched off temporarily (see "Switching the Devices Off" on page 14),
press any hardkey to turn the device on again.
When an IntelliVue Cableless Measurement Device is not operated, it will automatically switch off the
screen lighting after a short time. A little later the low-activity screen will be displayed.
10
Integrated monochrome LCD display
1
Hardkeys
2
3
Measurement identifier
