10 Specifications

IntelliVue CL NBP Pod Specifications

Complies with IEC 60601-2-30:1999/EN 60601-2-30:2000.
NOTE
The effectiveness of this sphygmomanometer has not been established in pregnant, including
pre-eclamptic patients.
Physical Specifications
Size (W x H x D)
Weight
Robustness
Ingress Protection
Environmental Specifications
Operating Temperature Range
Operating Humidity Range
Operating Altitude Range
Storage/Transportation Temperature
Range
Storage/Transportation Humidity
Range
Storage/Transportation Altitude Range -500 to 4600 m
IntelliVue CL NBP Pod Performance Specifications
Display Specifications
Type
Viewing Area
Dot Size
Resolution
Backlight
Sounds
74
65 mm x 138 mm x 30.5 mm ±5%
2.6 in x 5.4 in x 1.2 in ±5%
(without cradle and cuff)
220 g ±10%
7.8 oz ±10%
(without cradle and cuff)
Provides essential performance during exposure to random vibration
according to IEC TR 60721-4-7 Class 7M1
Survives shock, random vibration and bump according to IEC TR 60721-4-
7 Class 7M3 as well as a 1 m drop
IP32 according to IEC 60529 (protected against ingress of water when the
water is dripping vertically and the CL NBP Pod is tilted up to 15° and
protected against contact with or ingress of objects larger than 2.5 mm)
0 to 40°C (32 to 104°F)
≤95% RH @ 40°C (104°F)
-500 to 3000 m
-20 to 60°C (-4 to 140°F)
≤90% RH @ 60°C (140°F) (non-condensing)
monochrome (4 gray scales), passive LCD (STN), positive/transflective
25.6 mm x 19.2 mm
0.2 mm x 0.2 mm
128 x 96 pixel
white LED
Hardkey operation tone
Assignment tone
NBP done tone
INOP tone
