Performance Specifications
Measurement Range
Accuracy
Resolution
Sensors
LED Power Dissipation
Optical Output Power
Wavelength Range
Information about the wavelength range
can be especially useful to clinicians (for
instance, when photodynamic therapy is
performed)
For further information on accessory specifications, refer to the accessory Instructions for Use.
Display Specifications
Type
Viewing Area
Dot Size
Resolution
Backlight
Sounds
Battery
Runtime (fully charged battery)
Charging Time
Short Range Radio Specifications
Type
Technology
Frequency band
Modulation
Bandwidth
Effective radiated power (ERP)
Electronic Article Surveillance (EAS) EAS tag inside the housing
Real Time Clock Accuracy
30 to 300 bpm
±2% or 1 bpm, whichever is greater
1 bpm
Temperature rise at sensor skin interface in compliance with ISO 9919
≤15 mW
500 to 1000 nm
monochrome (4 gray scales), passive LCD (STN), positive/transflective
25.6 mm x 19.2 mm
0.2 mm x 0.2 mm
128 x 96 pixel
white LED
Hardkey operation tone
INOP tone
Integrated rechargeable Li-Ion battery with battery gauge and cycle counter
Continuous measurement:
Typically 24 hours
Intermittent measurement:
Typically 60 hours with repetition interval of 2 minutes
Typically 3 days with repetition interval of 5 minutes
max 2.5 hours
built in interface with integrated antenna
IEEE 802.15.4
2.4 GHz ISM (2.400 - 2.483 GHz)
DSSS (O-QPSK)
5 MHz
max. 0 dBm (1 mW)
less than 5 seconds per day (typically) as long as device is in power state
"Device on" or "Device off". Automatically synchronized with assigned
host system.
10 Specifications
73
