10 Specifications
IntelliVue CL Transmitter Base Station
Specifications
Physical Specifications
Size (W X H X D)
Weight
Robustness
Ingress Protection
Environmental Specifications
Operating Temperature Range
Operating Humidity Range
Operating Altitude Range
Storage/Transportation Temperature
Range
Storage/Transportation Humidity
Range
Storage/Transportation Altitude Range -500 to 4600 m
Performance Specifications
Charging Interface (output)
Power output (PoE powered)
Power output (USB powered)
Communication
USB Interface
Standard
Power Input
Connector
Network
Standards
Connector
80
75 mm x 45 mm x 173 mm ±5%
3.0 in x 1.8 in x 6.8 in ±5%
210 g ±10%
7.4 oz ±10%
Operating within specification during exposure to random vibration
according to IEC TR 60721-4-7 Class 7M1
Survives shock and 0.05 m free fall according to IEC TR 60721-4-7 Class
7M1
IP21 according to IEC60529 (protection against ingress of water when the
water is dripping vertically)
0 to 40°C (32 to 104°F)
≤95% RH @ 40°C (104°F)
-500 to 3000 m
-500 to 2000 m when powered from external power supply 865222 #E90
-20 to 60°C (-4 to 140°F)
≤90% RH @ 60°C (140°F)
no condensation
5V ±10%
USB input voltage - 180mV (@500mA)
USB 2.0 full speed
USB 2.0 full speed Device Port
4.5V - 5.5V (8W)
power requirement for service and upgrade of connected Cableless
Measurement Devices 2.5W
USB series "Standard-B" receptacle
IEEE 802.3 10-Base-T, IEEE 802.3af (PoE Class 3)
RJ45 (8 pin)
