Wiring Instructions

4. Wiring Instructions
An AYC-x6355 unit is supplied with a 10-conductor 56-cm (22-in.)
pigtail with exposed wires coated with solder.
4.1

Wiring the Unit as a Reader

If you connect the unit to a standard access control unit, it
automatically functions as a reader.
To connect the unit as a reader to an access control unit:
1. Select the appropriate connections according to Table 1.
2. Prepare the controller cable by cutting its jacket back about 3 cm
(1¼") and strip the insulation from the wires about 1.3 cm (½").
3. Splice the reader's pigtail wires to the corresponding controller
wires and cover each joint with insulating tape.

Table 1: Wiring the Unit as a Reader to a Control Panel

Wire Color
Red
Black
Green
White
Orange
Brown
Purple
Yellow
Blue
Gray
* These wires have programmable functions that may be adjusted by
presenting a configuration card within 10 seconds upon powering on the
unit. See the
Manual
for how you can create a configuration card.
** RS-485 is used for firmware update.
AYC-x6355 (Rev. B) Installation and User Manual
CS-CCT Configuration Card Tool for the DR-6255 Software
Output
Power
Ground
Data 0 / Data / C2
Data 1 / Clock / C1
Green LED Control*
Red LED Control*
Tamper Output
Buzzer Control*
RS-485 - A / OSDP**
RS-485 - B / OSDP**
15
