Controller Functionality

Table 7: Quick Reference Guide for Auxiliary Mode Setting

Aux. Aux. Input
Mode Function
0 AUX REX
1 Normal/Secure
switch
2 Normal/Secure
switch
3 Normal/Secure
switch
6 Door Monitor
7 Door Monitor
The following subsections describe each Auxiliary mode.
7.9.9.1 Auxiliary Mode 0
Auxiliary input function: Activates the auxiliary output
Auxiliary output activated by: Valid user code, Auxiliary code, and
Auxiliary input
For example, in Auxiliary Mode 0, the controller can function as a
2-door controller. The auxiliary relay is to be attached to the lock on
the second door. The auxiliary setting defines the door open time for
the second door. The auxiliary input is to be attached to the REX
pushbutton for the second door. The Door Monitor input feature for
the second door is not enabled when using this mode.
7.9.9.2 Auxiliary Mode 1
Auxiliary input function: Toggles Normal/Secure modes
Auxiliary output activated by: Valid user code, Auxiliary code
For example, in Auxiliary Mode 1, the controller can function as a
2-door controller. The auxiliary relay is to be attached to the lock on
the second door. The REX feature for the second door is not enabled
when using this mode.
AYC-x6355 (Rev. B) Installation and User Manual
Aux. Output
Activated by
Valid code or AUX
REX
Valid code
Star button (*)
Tamper event
Forced door
Door ajar
Aux. Aux. Settings
Relay (in seconds)
N.O. 01 to 99 Aux. relay
release time
N.O. 01 to 99 Aux. relay
release time
N.O. 01 to 99 Aux. relay
release time
N.C. 01 to 99 Aux. relay
release time
N.C. 01 to 99 Forced
delay
N.C.
01 to 99 Ajar delay
