- Page 1 AYC-F/G/M60 Series Convertible Reader with Genuine ™ HID Technology Installation and Programming Manual AYC-F60 AYC-G60 AYC-M60...
- Page 2 ROSSLARE. ROSSLARE reserves the right to revise and change this document at any time, without being obliged to announce such revisions or changes beforehand or after the fact.
-
Page 3: Table Of Contents
4.2.3 Selecting Keypad Transmission Format ......... 21 4.2.4 Selecting HID Prox Card Transmission Format ....... 26 4.2.5 Selecting Rosslare Proximity Card Transmission Format ....26 4.2.6 Changing the Programming Code ..........28 4.2.7 Changing the Facility Code ............29 4.2.8 Setting the Backlight Behavior ............ - Page 4 Table of Contents Normal, Secure, and Master Users .......... 32 Modes of Operation .............. 33 5.2.1 Normal Mode ................33 5.2.2 Bypass Mode ................33 5.2.3 Secure Mode ................34 5.2.4 Changing the Modes of Operation ..........34 Auxiliary Input and Output............. 36 Door Alarms .................
- Page 5 Table of Contents 5.9.15 Relay Codes Assignment ............... 59 5.9.16 PIN Code Length/Factory Default Settings ........61 5.9.17 Replacing a Lost Programming Code ..........62 5.9.18 Replacing a Lost Normal/Secure Code ........... 62 Declaration of Conformity........63 Limited Warranty ............64 AYC-F/G/M60 Series Installation and Programming Manual...
- Page 6 List of Figures List of Figures Figure 1: Drilling and Mounting Holes ............. 13 Figure 2: Controller Application Wiring Diagram ..........16 Figure 3: Controller Wiring – Using the Internal Power ........17 Figure 4: Controller Wiring – Using the External Power ........17 AYC-F/G/M60 Series Installation and Programming Manual...
- Page 7 List of Tables List of Tables Table 1: Wiring the Reader to the Controller ........... 14 Table 2: Wiring the Unit as a Controller............15 Table 3: Reader Programming Menu ............... 19 Table 4: Controller Programming Menu ............38 Table 5: Quick Reference Guide for Auxiliary Mode Setting ......46 AYC-F/G/M60 Series Installation and Programming Manual...
- Page 8 ROSSLARE exclusive warranty and liability is limited to the warranty and liability statement provided in an appendix at the end of this document.
-
Page 9: Introduction
Genuine HID Technology and outputs HID Prox card data in Wiegand according to the number of bits of data stored on the card. The units also read Rosslare proximity cards (125 kHz) and can output Rosslare proximity card data as Wiegand 26-Bit, Clock & Data, and Wiegand + PIN. -
Page 10: Ancillary Equipment
Wiegand or Clock & Data communication protocols. Multiple keypad formats are supported. For a complete list, see Section 4.2.3. UL installations require a UL listed access control units such as Rosslare's AC-215U and AC-225U. When functioning as a controller: Secured intelligent power supply –... -
Page 11: Technical Specifications
Programmable PIN code formats (see Section (Reader) 4.2.3) LED Indicators Two tri-colored LEDs Communication Data1/C1, Data0/C2–open collector, 5 V termination Measured using a Rosslare proximity card or equivalent. Range also depends on electrical environment and proximity to metal. AYC-F/G/M60 Series Installation and Programming Manual... - Page 12 Technical Specifications Environmental Characteristics Operating Temp. Range -30°C to 65°C (-22°F to 150°F) Operating Humidity Range 0 to 95% (non-condensing) Outdoor Usage Weather-resistant, meets IP65, epoxy-potted, suitable for indoor and outdoor use Physical Characteristics Size (Height x Width x F: 120 x 76 x 21 mm (4.7 x 3.0 x 0.8 in.) Depth) G: 137 x 44 x 21 mm (5.4 x 1.7 x 0.8 in.) M: 93 x 93 x 18 mm (3.6 x 3.6 x 0.7 in.)
-
Page 13: Installation
Installation Installation Installation of an RFID reader adjacent to metallic surfaces might alter the reader’s specifications. To diminish this interference, use a plastic spacer when mounting the reader. Before starting, select the location to mount the unit. This location should be at shoulder height. Mounting Before starting, select the location to mount the unit. -
Page 14: Wiring
Installation 6. Insert the unit’s cable wire into the cable hole and wire the unit as described in Section 3.2. 7. Screw the back cover to its mounting location. 8. Carefully re-attach the front cover of the unit. 9. Secure the front cover by using the supplied security Torx screw. A Torx security screw tool is provided to tighten the security Torx screw. -
Page 15: Wiring The Unit As A Controller
3.2.2 Wiring the Unit as a Controller If you connect the unit to a Rosslare PS-x25x secured power supply, it automatically functions as a controller. To connect the unit as a controller: 1. Select the appropriate connections according to Table 2. -
Page 16: Figure 2: Controller Application Wiring Diagram
Installation 4. Trim and cover all conductors not used. 5. To connect the unit to the desired power supply option, refer to the relevant wiring diagrams that follow. Figure 2 shows the wiring for the controller application using a dual relay secured intelligent power supply. -
Page 17: Figure 3: Controller Wiring - Using The Internal Power
Installation Figure 3 shows the auxiliary output connection using the internal power. Figure 3: Controller Wiring – Using the Internal Power Transorb:1.5 77c-Connect to load terminals (optional transorb for inductive loads,not supplied) Figure 4 shows the auxiliary output connection using the external power. -
Page 18: Reader Operation
Keypad data can be sent via one of eight keypad transmission formats. For more information, see Section 4.2.3. Rosslare proximity cards presented to the reader can output card data as Wiegand 26-Bit, Clock & Data, and Wiegand + PIN. See Section 4.2.5 for more information. -
Page 19: Table 3: Reader Programming Menu
Table 3: Reader Programming Menu Menu Description Default Selecting Keypad Transmission Format Single Key, Wiegand 6-Bit (Rosslare Format) Single Key, Wiegand 6-Bit with Nibble + Parity Bits Single Key, Wiegand 8-Bit, Nibbles Complemented 4 Keys Binary + Facility code, Wiegand 26-Bit... -
Page 20: Entering Programming Mode
Reader Operation 4.2.1 Entering Programming Mode To reach the Programming Menu System, the unit must first be placed into Programming mode. • The factory 4-digit Programming code is 1234. • If a Programming code is not entered within 30 seconds, the unit returns to Standby mode. -
Page 21: Selecting Keypad Transmission Format
2. Press 1 to enter Menu 1. The left LED turns red. Red Green 3. Enter one of the following codes: 1 – Single Key, Wiegand 6-Bit (Rosslare Format) (default) 2 – Single Key, Wiegand 6-Bit with Nibble + Parity Bits ... - Page 22 Standby mode and the keypad transmission format remains unchanged. 4.2.3.1 Single Key, Wiegand 6-Bit (Rosslare Format) Each key press immediately sends 4 bits with 2 parity bits added – even parity for the first 3 bits and odd parity for the last 3 bits.
- Page 23 Reader Operation 4.2.3.4 4 Keys Binary + Facility Code, Wiegand 26-Bit This option buffers 4 keys and outputs keypad data with a 3-digit facility code like a standard 26-bit card output. The facility code is set in Programming Menu 4 and can be in the range 000 to 255.
- Page 24 Reader Operation keypad PIN codes that are 5 digits in length, on the fifth key press of the 5-digit PIN code, the data is sent across the Wiegand Data lines as binary data in the same format as a 26-bit card. If * is pressed during PIN code entry or a PIN code greater than 65,535 is entered, the keypad clears the PIN code entry buffer, generates a beep and is ready to receive a new 5-digit keypad PIN...
- Page 25 Reader Operation A = The first key entered D = Fourth key entered B = Second key entered E = Fifth key entered C = Third key entered F = Sixth key entered 4.2.3.7 Single Key, 3x4 Matrix Keypad This unique mode is intended to let the host controller scan the keypad while still keeping the proximity card readers Wiegand 26-Bit or Clock &...
-
Page 26: Selecting Hid Prox Card Transmission Format
Selecting Rosslare Proximity Card Transmission Format The AYC-F/G/M60 can read Rosslare proximity cards (125 kHz) and can output Rosslare proximity card data as Wiegand 26-Bit, Clock & Data, and Wiegand + PIN. To select the Rosslare prox imity card transmission format: 1. - Page 27 Reader Operation 3. Enter one of the following codes: 1 – Wiegand 26-Bit 2 – Clock & Data 3 – Wiegand Card + PIN If an incorrect option is entered, the reader returns to Standby mode and the keypad transmission format remains unchanged. You hear three beeps.
-
Page 28: Changing The Programming Code
Reader Operation PIN Data: (EP) 0000 AAAA BBBB CCCC DDDD EEEE (OP) Where: A = The first key entered D = Fourth key entered B = Second key entered E = Fifth key entered C = Third key entered EP = Even parity for first 12 bits OP = Odd parity for last 12 bits If the PIN code is less than 5 digits, all the most significant nibbles are filled with 0. -
Page 29: Changing The Facility Code
Reader Operation 4.2.7 Changing the Facility Code • The Facility code can be in the range of 000 to 255. • The default Facility code is 0. To change the Facility code: 1. Enter Programming mode. Green 2. Press 4 to enter Menu 4. The left LED turns red. -
Page 30: Setting The Credential Format
3. Enter one of the following codes: 61 for Rosslare Proximity 62 for HID Prox 63 for Rosslare Proximity + HID Prox (default) You hear three beeps. The system returns to Standby mode. 4.2.10 Return to Factory Default Settings... -
Page 31: Replacing A Lost Programming Code
Reader Operation 3. Enter your 4-digit Programming code. If the Programming code is valid, all memory is erased, you hear three beeps and the controller returns to Normal mode. If the Programming code is invalid, you hear a long beep and the controller returns to Normal mode without erasing the memory of the controller. -
Page 32: Controller Operation
The Lock Strike Output and REX input are located on the Rosslare secured intelligent power supply and not on the unit unit, thus eliminating the possibility of unauthorized entry to the restricted area. -
Page 33: Modes Of Operation
Controller Operation Secure A Secure user must have a Primary and Secondary code programmed; the two codes must not be the same. The Secure user can gain access when the unit is in any of its three modes of operation. -
Page 34: Secure Mode
Controller Operation 5.2.3 Secure Mode The left LED is red. Only Secure and Master users can access the premises in Secure mode. A Secure user must enter the Primary and Secondary codes to gain entry. After entering the Primary code, the right LED flashes green for 10 seconds, during which the Secondary code must be entered. - Page 35 Controller Operation 2. Press # to confirm the mode change. The left LED stops flashing. Green 5.2.4.3 Changing from Normal Mode to Bypass Mode See Section 5.9.7 to create/modify the Normal/Bypass code. To change from Normal to By pass mode: 1.
-
Page 36: Auxiliary Input And Output
Controller Operation Auxiliary Input and Output For optimum usability in different applications, the controller’s auxiliary input and output can be configured in 10 different modes of operation (see Section 5.9.9). Door Alarms Door alarms can be generated by connecting the Auxiliary Input to a Door Position Switch. -
Page 37: Rex Function
Controller Operation REX Function The REX button is connected to Rosslare’s secured intelligent power supply. The REX button must be located inside the premises to be secured and is used to open the door without the use of a PIN code. It is usually located in a convenient location, such as inside the door or at a receptionist's desk. -
Page 38: Programming As A Controller
Controller Operation Programming as a Controller Programming is done solely via the unit's keypad driven Programming Menu System. To reach the Programming Menu System, the unit must first be put into Programming mode (see Section 5.9.1). During the manufacturing process, certain codes and settings are pre- programmed. -
Page 39: Entering Programming Mode
Controller Operation You will find instructions for each of the above menu items in the following subsections. 5.9.1 Entering Programming Mode • The unit must be in Normal mode to enter Programming mode. • The factory four-digit Programming code is 1234. •... -
Page 40: Changing Lock Strike Code
Controller Operation 5.9.3 Changing Lock Strike Code The Lock Strike code is mainly used as a method to quickly test the Lock Strike Relay during installation. When the first user is added to the controller, the default Lock Strike code is automatically deleted. Once the code is programmed again, it is not deleted with the entry of additional user codes. -
Page 41: Changing The Programming Code
Controller Operation To change the Aux iliary code: 1. Enter Programming mode. Green 2. Press 2 to enter Menu 2. The left LED turns orange. Orange Green 3. Enter the new Auxiliary code. You hear three beeps. Green The system returns to Normal mode. 5.9.5 C hanging the Programming Code 4 3 B... -
Page 42: Changing The Normal/Secure Code
Controller Operation 5.9.6 Changing the Normal/Secure Code • Code 0000 erases the Normal/Secure code. • This code is disabled if the Auxiliary Input is set to toggle between Normal and Secure access modes. • The default Normal/Secure code is 3838. To change the Normal/ Secure code: 1. -
Page 43: Setting Fail Safe/Secure Operation, Tamper Siren And Lock Strike Release Time
Controller Operation 3. There are four different ways to program the Normal/Bypass code and door chime: Disable both Bypass code and the door chime. Enter the code 0000. Disable Bypass code and enable the door chime. Enter the code 0001. Enable Bypass code and disable the door ... -
Page 44: Defining The Auxiliary Input And Output
Controller Operation Construct a code using the following instructions: First digit For Fail Secure Operation, the first digit should be 0. For Fail Safe Operation, the first digit should be 1. Second digit Siren Time in minutes (1–9, 0 – disabled) ... - Page 45 Controller Operation 3. Construct a code using the following instructions: Second digit (Auxiliary Mode) In addition to the Lock Strike Relay and Lock Strike REX, the unit features an Auxiliary Input. The Auxiliary mode defines the function of the Auxiliary Input. Third and fourth digits (Auxiliary Setting) ...
-
Page 46: Table 5: Quick Reference Guide For Auxiliary Mode Setting
Controller Operation Table 5: Quick Reference Guide for Auxiliary Mode Setting Aux. Aux. Input Aux. Aux. Aux. Settings Mode Function Output Relay (in seconds) Activated AUX REX Valid code or N.O. 01 to 99 Aux. relay AUX REX release time 00 Aux. - Page 47 Controller Operation The following subsections describe each Auxiliary mode. 5.9.9.1 Auxiliary Mode 0 Auxiliary input function: Activates the auxiliary output Auxiliary output activated by: Valid user code, Auxiliary code, Auxiliary input For example, in Auxiliary Mode 0, the controller can function as a two-door controller.
- Page 48 Controller Operation modes. By connecting a switch timer or alarm system output to the auxiliary input, the controller can be automatically switched from Normal mode (during office hours) to Secure mode (after office hours). 5.9.9.4 Auxiliary Mode 3 Auxiliary input function: Toggles Normal/Secure modes Auxiliary output activated by: Alarms For example, in Auxiliary Mode 3, the auxiliary output is activated if the controller is tampered;...
- Page 49 Controller Operation 5.9.9.6 Auxiliary Mode 5 Auxiliary input function: Door Monitor Auxiliary output activated by: Shunt (explanation below) For example, in Auxiliary Mode 5, the controller is capable of shunting an alarm system. In this mode, the auxiliary input is to be wired to the magnetic contact switch on the door.
- Page 50 Controller Operation and if the door does not close prior to the end of this period, the controller activates the auxiliary relay. The auxiliary setting defines the door-ajar time. 5.9.9.9 Auxiliary Mode 8 This mode controls the door indicator (right LED). The right LED is not lit when: •...
-
Page 51: Setting The Lockout Feature
Controller Operation 5.9.10 Setting the Lockout Feature Using the lockout feature is highly recommended, especially when using a short PIN code length (4 or 5 digits). If the controller is presented with wrong codes (PIN or card) consecutively several times, the unit goes into Lockout mode. When a lockout occurs, the controller keypad and reader are locked so no codes can be entered until the set lockout period expires. -
Page 52: Setting The Backlight Behavior
Controller Operation 5.9.11 Setting the Backlight Behavior The controller allows you to define the way the units' Backlight works. To set the backlight behavior: 1. Enter Programming mode. Green 2. Press 6 to enter Menu 6. The left LED flashes green. Green Green 3. -
Page 53: Enrolling Primary And Secondary Codes
Controller Operation 3. Enter the appropriate option number for the credential format: 6100 – Rosslare proximity 6200 – HID Prox 6300 – Rosslare proximity + HID Prox (default) 5.9.13 Enrolling Primary and Secondary Codes 5.9.13.1 Primary Codes ... - Page 54 Controller Operation Code Search Method The Code Search Method is mainly used when enrolling a user’s Secondary code and the User Slot code is unknown. The Code Search method only works if a user’s Primary code is already enrolled but the Secondary code is not (see Section 5.9.13.5).
- Page 55 Controller Operation 4. Perform one of the following: Enter the PIN code that you want to assign as the Primary or Secondary code for this slot number. Present the user card that you want to assign as the Primary or Secondary code for this slot number.
-
Page 56: Deleting Primary And Secondary Codes
Controller Operation 4. Perform one of the following: Enter the PIN code belonging to the user for whom you wish to add a Secondary code. Present the user card belonging to the user for whom you wish to add a Secondary code. The left LED flashes red. - Page 57 Controller Operation 5.9.14.1 Deleting Primary and Secondary Codes using the Standard Method To delete the Primary and Secondary codes using the Standard Method: 1. Enter Programming mode. Green 2. Press 8 to enter Menu 8. The left LED turns red and the right LED turns orange.
- Page 58 Controller Operation 5.9.14.2 Deleting Primary and Secondary codes using the Code Search Method To delete the Primary and Secondary codes using the Code Search Method: 1. Enter Programming mode. Green 2. Press 8 to enter Menu 8. The left LED turns red and the right LED turns orange.
-
Page 59: Relay Codes Assignment
Controller Operation 5. Enter your 4-digit Programming code to confirm the deletion. If the Programming code is valid, you hear three beeps and the unit returns to Normal mode. If the Programming code is invalid, you hear a long beep and the unit returns to Normal mode. - Page 60 Controller Operation If the assignment code is valid, the mode indicator stops flashing. The controller is now waiting for another slot number. 5. Do one of the following: Press # to move to the next available user slot number. Enter another 3-digit user slot number.
-
Page 61: Pin Code Length/Factory Default Settings
Controller Operation 5. Enter the assignment digit for the current user slot: 1 activates the Lock Strike relay only default 2 activates the Auxiliary relay only 3 activates the Lock Strike and Auxiliary relays If the assignment digit is valid, three beeps are heard and the controller returns to Normal mode. -
Page 62: Replacing A Lost Programming Code
Controller Operation If the Programming code is valid, all memory is erased. You hear three beeps and the controller returns to Normal mode. If the Programming code is invalid, you hear a long beep and the controller returns to Normal mode without erasing the memory contents. -
Page 63: Declaration Of Conformity
Declaration of Conformity Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference. This device must accept any interference received, including ... -
Page 64: Limited Warranty
The full ROSSLARE Limited Warranty Statement is available in the Quick Links section on the ROSSLARE website at www.rosslaresecurity.com. Rosslare considers any use of this product as agreement to the Warranty Terms even if you do not review them. AYC-F/G/M60 Series Installation and Programming Manual... - Page 65 +86 755 8610 6842 Fax: +86 755 8610 6101 Rosslare Security Products, Inc. support.cn@rosslaresecurity.com Southlake, TX, USA Toll Free: +1-866-632-1101 India Local: +1-817-305-0006 Rosslare Electronics India Pvt Ltd. Fax: +1-817-305-0069 Tel/Fax: +91 20 40147830 support.na@rosslaresecurity.com Mobile: +91 9975768824 Europe sales.in@rosslaresecurity.com Rosslare Israel Ltd.
- Page 66 FCC Warning: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
