Rosslare Multi-Smart AY-K35 Installation & User Manual

Multi-Smart™ Readers
125 kHz, 13.56 MHz, Bluetooth®
and NFC
Installation & User Guide
1. Introduction
The innovative Multi-Smart™ Readers from Rosslare support multiple technologies: BLE (Bluetooth Low Energy), NFC,
125 kHz and 13.56 MHz RFID. Multi-technology Multi-Smart™ Readers are especially suited for sites that need more
than one RFID credential or use more than one CSN Select credential. The readers supports ASK and FSK for 125 kHz
and 13.56 MHz smartcards to read the RFID transponder UID and output the ID to the control panel. The reading
capability includes sector read at 13.56 MHz. This feature supports all RFID types in one reader without updating
legacy credentials in the system.
The Multi-Smart™ Readers read Rosslare BLE-ID™ and NFC-ID™ credentials generated by the BLE-ID™ mobile app or
the mobile credentials SDK that run on a user's iOS or Android smartphone. The BLE-Admin™ app can configure which
technologies are used by each reader.
The readers support SIA Open Supervised Device Protocol (OSDP V2) including SCP mode (Secured Channel
Protocol), allowing readers to connect to any controller that supports OSDP.
The readers also have a capacitive touch button on the surface which can be assigned functions such as Door Bell,
Exit, Help, Lights or other required outputs.
With simple installation, the readers allow you to easily manage add-ons installations and technology migrations. They
come in a modern small model that fit any architecture design, and are suitable for outdoor use. In addition, they are CE
and FCC certified.
1.1. Installation Kit
The installation kit consists of the following items to be used during the installation procedure.
Description
Self-adhesive mounting label template
Flat screw M3.5 x 25 mm
Plastic anchor M6 x 30 mm
Torx tamper proof screwdriver
Torx screw M3 x 5 mm
Bell sticker
www.rosslaresecurity.com
1
Quantity
1
2
2
1
1
4
