17.11 Operability; 17.12 Certificates And Approvals - Endress+Hauser HART Proline Prosonic Flow B 200 Operating Instructions Manual

Technical data
Local operation
Remote operation
Languages
CE mark
104

17.11 Operability

Order characteristic for "Display; Operation", option C
Display elements
• 4-line display
• Format for displaying measured variables and status variables can be individually configured
• Permitted ambient temperature for the display: –20 to +60 °C (–4 to +140 °F)
The readability of the display may be impaired at temperatures outside the temperature range.
Operating elements
• Local operation with 3 push buttons ( ,
• Operating elements also accessible in various hazardous areas
Additional functionality
• Data backup function
The device configuration can be saved in the display module.
• Data comparison function
The device configuration saved in the display module can be compared to the current device
configuration.
• Data transfer function
The transmitter configuration can be transmitted to another device using the display module.
Via HART protocol
Operation via:
• HART protocol
• Operating tools via FXA191, FXA195
– FieldCare (® ä 105)
– AMS Device Manager
– SIMATIC PDM
• HART handheld terminals
– Field Communicator 375, 475
– Field Xpert SFX100
Via service interface (CDI)
Operation via:
• Service interface (CDI) of the measuring device
• "FieldCare" operating tool via Commubox FXA291
Local operation possible in the following languages:
English, German, French, Spanish, Italian, Dutch, Portuguese, Polish, Turkish, Chinese, Japanese,
Korean, Bahasa (Indonesian), Vietnamese, Czech

17.12 Certificates and approvals

The measuring system is in conformity with the statutory requirements of the applicable EC
Directives. These are listed in the corresponding EC Declaration of Conformity along with the
standards applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.
Proline Prosonic Flow B 200 HART
, )
E
Endress+Hauser
