Important information
DANGER
Dangerous state of the machine
Make sure that the dangerous state of the machine is (and remains) switched off
b
during mounting, electrical installation, and commissioning.
Make sure that the outputs of the safety light curtain do not affect the machine
b
during mounting, electrical installation, and commissioning.
DANGER
Hazard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
Only use the sender and receiver of the deTec4 Core Vibes safety light curtain with
b
each other. Do not use the sender or receiver of the deTec4 Core Vibes safety light
curtain with components from another safety light curtain or with components
from another safety light curtain of the deTec family.
Only use the brackets described in this document.
b
Take appropriate measures for vibration damping if vibration and shock specifica‐
b
tions exceed the values and test conditions specified in the data sheet,
nical data", page 54.
DANGER
Hazard due to lack of effectiveness of the protective device
Persons and parts of the body to be protected may not be recognized in case of non-
observance.
Do not do repair work on device components.
b
Do not make changes to or manipulate device components.
b
Apart from the procedures described in this document, the device components
b
must not be opened.
NOTE
Mount the device in the following order.
Prerequisites
The construction of the safety light curtain has been correctly executed.
Further topics
• "Design", page 16
• "Technical data", page 54
Approach
1. Check the components for completeness and the integrity of all parts.
2. Please contact your respective SICK subsidiary should you have any complaints.
