ORDERING INFORMATION

13 Ordering information
13.1

Scope of delivery

13.2

Ordering information deTec4 Core Vibes

60 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes
Scope of delivery, sender
• Sender
Scope of delivery, receiver
• Receiver
• Test rod with diameter corresponding to the resolution of the safety light curtain
Sender and receiver with low sensing range
Table 17: Ordering information deTec4 Core Vibes for 30 mm resolution
Protective field height in mm
300
450
600
750
900
1050
1200
1350
1500
1650
1800
1950
2100
Sender and receiver with medium sensing range
Table 18: Ordering information deTec4 Core Vibes for 30 mm resolution
Protective field height in mm
300
450
600
750
900
1050
1200
1350
1500
1650
1800
1950
2100
s Sender
Type code
C4C-SV03030C10000
C4C-SV04530C10000
C4C-SV06030C10000
C4C-SV07530C10000
C4C-SV09030C10000
C4C-SV10530C10000
C4C-SV12030C10000
C4C-SV13530C10000
C4C-SV15030C10000
C4C-SV16530C10000
C4C-SV18030C10000
C4C-SV19530C10000
C4C-SV21030C10000
s Sender
Type code
C4C-SV03030C10000
C4C-SV04530C10000
C4C-SV06030C10000
C4C-SV07530C10000
C4C-SV09030C10000
C4C-SV10530C10000
C4C-SV12030C10000
C4C-SV13530C10000
C4C-SV15030C10000
C4C-SV16530C10000
C4C-SV18030C10000
C4C-SV19530C10000
C4C-SV21030C10000
r Receiver
Type code
C4C-EV03030B10000
C4C-EV04530B10000
C4C-EV06030B10000
C4C-EV07530B10000
C4C-EV09030B10000
C4C-EV10530B10000
C4C-EV12030B10000
C4C-EV13530B10000
C4C-EV15030B10000
C4C-EV16530B10000
C4C-EV18030B10000
C4C-EV19530B10000
C4C-EV21030B10000
r Receiver
Type code
C4C-EV03030C10000
C4C-EV04530C10000
C4C-EV06030C10000
C4C-EV07530C10000
C4C-EV09030C10000
C4C-EV10530C10000
C4C-EV12030C10000
C4C-EV13530C10000
C4C-EV15030C10000
C4C-EV16530C10000
C4C-EV18030C10000
C4C-EV19530C10000
C4C-EV21030C10000
