O P E R A T I N G I N S T R U C T I O N S
deTec4 Core Vibes
Safety light curtain

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the deTec4 Core Vibes and is the answer not in the manual?

Questions and answers

Related Manuals for SICK deTec4 Core Vibes

Summary of Contents for SICK deTec4 Core Vibes

  • Page 1 O P E R A T I N G I N S T R U C T I O N S deTec4 Core Vibes Safety light curtain...
  • Page 2 Original document This document is an original document of SICK AG. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 3: Table Of Contents

    Unpacking....................Installation....................5.3.1 Mounting the QuickFix bracket..........8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 4 Accessories..................62 14.1 Brackets....................14.2 Mounting accessories................O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...
  • Page 5 List of figures..................68 List of tables..................69 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 6: About This Document

    Chapters not listed here are intended for all target groups. All target groups must take into account the safety and warning instructions of the complete operating instructions! O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 7: Additional Information

    Ö The LED is flashing. O The LED is illuminated continuously. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 8 The symbol indicates the sender. The symbol indicates the receiver. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 9: Safety Information

    8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 10 47, and see "Regular cleaning", page O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 11: Product Description

    The scanning range is the maximum protective field width. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 12: Product Characteristics

    The sender and receiver LEDs indicate the operational status of the safety light curtain. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...
  • Page 13 The blue alignment quality light emitting diodes in combination with the red flashing ERR LED also denote faults. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 14: Example Applications

    Figure 5: Hazardous point protection Figure 6: Access protection O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 15: Hazardous Area Protection

    PRODUCT DESCRIPTION Figure 7: Hazardous area protection 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 16: Project Planning

    Overview This chapter contains important information about the design. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 17: Scanning Range And Protective Field Width

    8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 18 ° The reach or approach speed is already included in the formula. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 19: Minimum Distance To The Hazardous Point For Orthogonal (Rectangular) Approach To The Protective Field

    8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 20: Minimum Distance To Reflective Surfaces

    Make sure that no dispersive media (e.g., dust, fog, or smoke) are within the calcu‐ lated minimum distance from the protective field. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 21: Graph Of Minimum Distance From Reflective Surfaces

    D ≤ 3 m a = 131 mm 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 22: Protection Against Interference From Systems In Close Proximity To Each Other

    "Using reversed direction of transmission", page 23 • "Maintaining sufficient distance", page 23 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 23: Trouble-Free Operation Due To Reversed Direction Of Transmission Of System 1 And System 2

    Receiver with high sensing sensing range 34 m 12 m 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 24: Integration In Electrical Control

    O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 25: Dual-Channel And Isolated Connection Of Ossd1 And Ossd2

    8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 26: No Potential Difference Between Load And Protective Device

    (SELV/PELV). Suitable power supply units are available as accessories from SICK, see "Accessories", page O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 27: Restart Interlock

    OSSDs are switched off. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 28: Connection Diagrams

    The definition must be based on the application conditions and the risk assess‐ ment and must be documented in a traceable manner. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 29: Test Rod Check

    The test is carried out with an opaque test rod whose diameter corresponds to the reso‐ lution of the safety light curtain. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 30 The OSSD LED must not illuminate green. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 31: Test Rod Check: Step 1

    The OSSD LED must not illuminate green. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 32: Visual Check Of The Machine And The Protective Device

    O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 33: Mounting

    Please contact your respective SICK subsidiary should you have any complaints. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 34: Installation

    Figure 22: Sender and receiver must not be installed such that they are rotated 180° relative to each other O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...
  • Page 35 (§). 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 36 (%). O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 37: Mounting The Quickfix Bracket

    The QuickFix bracket has cable routing. Depending on the installation, the cable routing can make mounting easier. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 38: Mounting The Quickfix Bracket To A Profile

    Mounting on the side Mounting on the back O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 39: Electrical Installation

    • Mounting has been correctly executed. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 40: System Connection (M12, 5-Pin)

    System connection (M12, 5-pin) Figure 26: System connection (male connector, M12, 5-pin) O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 41: System Connection Via Connection Cable (M12, 5-Pin To 8-Pin)

    TGS safety light curtain with a deTec4 Core Vibes, without having to route new cables. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 42: Commissioning

    • "Minimum distance to reflective surfaces", page 20 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 43: Overview

    "Indication of the alignment quality", page 45 • "Diagnostic LEDs", page 50 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 44: Aligning The Sender And Receiver

    "Mounting", page 33 • "Accessories", page 62 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 45: Alignment With The Quickfix Bracket

    Remove all objects from the protective field to allow the alignment quality to be assessed. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 46: Check During Commissioning And Modifications

    Carry out the checks according to the instructions from the manufacturer of the machine and from the operating entity. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 47: Operation

    Carry out the checks according to the instructions from the manufacturer of the machine and from the operating entity. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 48: Maintenance

    Make sure that no dispersive media (e.g., dust, fog, or smoke) are within the calcu‐ lated minimum distance from the protective field. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 49: Regular Thorough Check

    Carry out the checks according to the instructions from the manufacturer of the machine and from the operating entity. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 50: Troubleshooting

    Position of LEDs: see "Sender indicators", page O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 51: Fault Indicator On The Sender

    "Ordering infor‐ mation", page 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 52 LED off. Ö LED flashes. O LED illuminates. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 53: Decommissioning

    SICK will be glad to help you dispose of these devices on request. 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 54: Technical Data

    For more detailed information on the exact configuration of your machine, please consult your respective SICK subsidiary. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 55: Technical Data For Sender

    Air humidity (non-condensing) Storage temperature -30 °C +70 °C 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 56: Response Time

    2.11 1200 1.10 2.21 1350 1.15 2.30 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 57: Length Of Cable

    1120 1350 1240 1250 1500 1380 1390 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 58: Dimensional Drawings

    1362 1500 1512 1650 1662 1800 1812 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...
  • Page 59 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 60: Ordering Information

    C4C-EV18030C10000 1950 C4C-SV19530C10000 C4C-EV19530C10000 2100 C4C-SV21030C10000 C4C-EV21030C10000 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 61: Ordering Information Detec4 Core Vibes For 30 Mm Resolution

    C4C-EV18030A10000 1950 C4C-SV19530A10000 C4C-EV19530A10000 2100 C4C-SV21030A10000 C4C-EV21030A10000 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 62: Accessories

    Ambient operating temperature: Down to −30° C with fixed installation. O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 63: Alignment Aid

    Ambient operating temperature: Down to –30 °C with fixed installation 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 64: Cleaning Agent

    Test rod 30 mm 2022602 Test rod holder 2052249 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 65: Annex

    (part number: see the type label entry in the “Ident. no.” field). 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 66: Note On Specified Standards

    ISO 13849-1 GB/T 16855.1 ISO 13855 GB/T 19876 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...

  • Page 67: Checklist For Initial Commissioning And Commissioning

    8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...

  • Page 68: List Of Figures

    28. Dimensional drawing of sender and receiver............58 29. Dimensional drawing of the QuickFix bracket (2066048)........62 O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK...

  • Page 69: List Of Tables

    29. Ordering information, test rods..................64 30. Note on specified standards..................66 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 70 LIST OF TABLES O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes 8024467/2019-06-18 | SICK Subject to change without notice...
  • Page 71 LIST OF TABLES 8024467/2019-06-18 | SICK O P E R A T I N G I N S T R U C T I O N S | deTec4 Core Vibes Subject to change without notice...
  • Page 72 E-Mail office@sick.com.gr E-Mail info@sick.ru Vietnam Hong Kong Singapore Phone +65 6744 3732 Phone +852 2153 6300 Phone +65 6744 3732 E-Mail sales.gsg@sick.com E-Mail ghk@sick.com.hk E-Mail sales.gsg@sick.com Detailed addresses and further locations at www.sick.com SICK AG | Waldkirch | Germany | www.sick.com...
