SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
–
TM
SmartVu
2.3
Dec 4, 2020
61 OF 168
Controls IOM
4.15.
19DV Device Status Display Screens
4.15.1. System Overview
The f ollowing screen is the system overview screen (default screen), by clicking the component in this
screen, user can enter the specific component screen, or clicking the bottom in home page.
61
