19XR6/7/F Device Status Display Screens
The following screens are designed for end user to check the components status.
4.13.1. System Overview
The following screen is the system overview screen (default screen), by clicking the component
in this screen, user can enter the specific component screen, or clicking the bottom in home
page.
49
