Event States - Carrier SmartVu Control Manual

Alt-175 ALT-175 Master Slave
Alert - ncorrect Master
Control Type
Alt-176 ALT-176 Master Slave
Alert - No
Communication Master /
Slave
Alt-179 ALT-179 Master Slave
Alert - aster CCN Write
Rejection
Alt-180 ALT-180 Master Slave
Alert - Slave address not
slave
ALT-181 ALT-181 Loss
Communication with
AHF GDCB 1
ALT-182 ALT-182 Loss
Communication with
AHF GDCB 2
ALT-183 ALT-183 Loss
Communication with
AHF GDCB 3
ALT-184 ALT-184 Loss
Communication with
AHF GDCB 4
ALT-185 ALT-185 AHF GDCB 1
Start Failure
ALT-186 ALT-186 AHF GDCB 2
Start Failure
ALT-187 ALT-187 AHF GDCB 3
Start Failure
ALT-188 ALT-188 AHF GDCB 4
Start Failure
ALT-189 Process Alert - Low Oil
Supply Temperature
ALT-190 AHF FAULT
ALT-191 Loss Communication
with AHF

6.5. Event States

A event state is a specific set of conditions which the controller may encounter when controlling the
chiller. Event states are predictable and repeatable and represent known states of the control. If the
control is in a particular state, there is a unique message associated with that state. The event states
message are displayed on default screen of control panel.
Event No. Description of event state
1 Chiller Off
2 Chiller Tripout
3 Pumpdown/Lockout
4 Terminate Pumpdown/Lockout
5 Guide Vane 1 Calibration
6 Quick Test in Progress
7 Ice Build Done
8
Ice Build in Progress
9
Free Cooling in Progress
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
Manual As above
Automatic As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
Manual As above
REVISION DATE
2.3 Dec 4, 2020
Check master control type
Check communication between master and
slave, wiring, etc.
Check CCN communication, hardware and
software
Check master slave configurations
Check the communication configurations
between the main control board and GDCB1
board, and the cables, etc.
Check the communication configurations
between the main control board and GDCB2
board, and the cables, etc.
Check the communication configurations
between the main control board and GDCB3
board, and the cables, etc.
Check the communication configurations
between the main control board and GDCB4
board, and the cables, etc.
Check AHF GDCB board 1 and the related
configurations
Check AHF GDCB board 2 and the related
configurations
Check AHF GDCB board 3 and the related
configurations
Check AHF GDCB board 4 and the related
configurations
If oil supply temperature is less than the 95
F during chiller is running and oil exv is
enabled
Receive the fault state
Check the communication with AHF every
1s, if no response, it will alert
