Carrier SmartVu Control Manual page 158

0 to 12000
18 chwf_bas 0.00 to 34,065.00
0 to 9000
19 evpd_bas 0.00 to 137.90
0 to 20
20 cdwf_bas 0.00 to 34,065.00
0 to 9000
21 cdpd_bas 0.00 to 137.90
0 to 20
22 wpd_20ma 68.95 to 275.80
10 to 40
23 blank -
24 mrn_opt DSABLE_ENABLE
25 mrn_pt DSABLE_ENABLE
26 pr_opt DSABLE_ENABLE
27 cpr_opt DSABLE_ENABLE
28 cfa_opt DSABLE_ENABLE
*Depends on the selected language (English by default).
CFGUMVFD - VFD Parameters
Name Range
1 comp_hz 47 to 200
2 rlv_i 200 to 13800
3 rla 10 to 2000
4 rla_load 10 to 2000
5 rlv 200 to 13800
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
0 GPM
0.00 l/min
0 GPM
0.00 kPa
0 PSI
0.00 l/min
0 GPM
0.00 kPa
0 PSI
68.95 kPa
10 PSI
- -
DSABLE -
DSABLE -
DSABLE -
DSABLE -
DSABLE -
Default Unit
50 Hz
460 V
200 A
200 A
460 V
REVISION DATE
2.3 Dec 4, 2020
Evap Flow Rate Baseline
Evap Pres Drop Baseline
Cond Flow Rate Baseline
Cond Pres Drop Baseline
Water Pres Drop @20mA
Marine Option
Marine Transducer Option
Marine Pwr Req Option
Marine Cont. Pwr Req
Condenser Flush Alert
Displayed text*
Compressor Speed 100%
Rated Line Voltage
Motor Nameplate Current
Motor Rated Load Current
Motor Nameplate Voltage
PAGE
158 OF 168
158
