Carrier SmartVu Control Manual page 110

Communication Failure
Alm-300 ALM-300 Loss
Communication With
ISM
Alm-301 ALM-301 Loss
Communication With
IOB1
Alm-302 ALM-302 Loss
Communication With
IOB2
Alm-303 ALM-303 Loss
Communication With
IOB3
Alm-304 ALM-304 Loss
Communication With
IOB4
Alm-305 ALM-305 Loss
Communication With
IOB5
Alm-306 ALM-306 Loss
Communication With
SIOB
Alm-307 ALM-307 LEN Scan
Error
Alm-308 ALM-308 Loss
Communication With
VFD
Alm-309 ALM-309 Loss
Communication With
VFD Gateway (LEN)
Alm-310 ALM-310 Loss
Communication With
VFD (Modbus)
Alm-311 ALM-311 Loss
Communication With
Danfoss VFD
Alm-350 Sensor Fault - 19DV
1st Stage Bearing
Temp
Alm-351 Sensor Fault - 19DV
2nd Stage Bearing
Temp
Alm-352 Sensor Fault - 19DV
Pump Output Pressure
Alm-353 Sensor Fault - Heat
Reclaim Entering Temp
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
Automatic when Unit shuts
the communication down.
comes back to
normal
As above As above
As above As above
As above As above
As above As above
As above As above
As above As above
Manual As above
Automatic when As above
the communication
comes back to
normal
As above As above
As above As above
As above As above
As above As above
As above As above
As above As above
As above As above
REVISION DATE
2.3 Dec 4, 2020
Bus installation fault or defective slave
board
Bus installation fault or defective slave
board
Bus installation fault or defective slave
board
Bus installation fault or defective slave
board As above
Bus installation fault or defective slave
board
Bus installation fault or defective slave
board
Bus installation fault or defective slave
board
Check LEN bus hardware physical wiring
and software log
Bus installation fault or defective slave
board
Bus installation fault or defective slave
board
Bus installation fault or defective slave
board
If (vfd_opt = 7) AND {LEN side
Communication error with VFD lost for 14
[default, can be configurable] consecutive
seconds}
Tested when the compressor is on
whatever the run status and the
communication between Main board and
IOBs is ok, If compressor 1st Bearing
Temp is outside the range of -39.5 to
244.5°F
Tested when the compressor is on
whatever the run status and the
communication between Main board and
IOBs is ok, If compressor 2nd Bearing
Temp is outside the range of -39.5 to
244.5°F
Tested when the compressor is whatever
the run status and the communication
between Main board and IOBs is ok, if
Bearing Outlet Transducer voltage outside
Tested when the compressor is on
whatever the run status and the
communication between Main board and
IOBs is ok, If heat water entering
temperature is outside the range of -39.5
to 244.5°F
PAGE
110 OF 168
110
