Carrier SmartVu Control Manual page 104

Alm-218 ALM-218 Sensor Fault
- Diffuser Pressure
Alm-219 ALM-219 Sensor Fault
- Oil Sump Pressure
Alm-220 ALM-220 Sensor Fault
- Oil Supply Pressure
Alm-225 ALM-225 Sensor Fault
– Pump Inlet Pressure
Alm-226 ALM-226 Sensor Fault
– Bearing Inlet
Pressure
Prestart failure
Alm-230 ALM-230 Prestart
Failure - High Bearing
Temperature
Alm-231 ALM-231 Prestart
Failure - High Motor
Temperature
Alm-232 ALM-232 Prestart
Failure - High
Discharge Temp
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
As above As above
As above As above
As above As above
As above As above
As above As above
Manual Unit shuts
down.
Compressor
is not
allowed to
start
As above As above
As above As above
REVISION DATE
2.3 Dec 4, 2020
Check for disconnected, grounded, or
shorted wiring. Check for condensation in
transducer connector.
Check Diffuser pressure transducer wiring.
Confirm that 5 V reference signal is
available between IOB connector. Check
for disconnected, grounded, or shorted
wiring. Check for condensation in
transducer connector.
Check Oil Sump pressure transducer
wiring. Confirm that 5 V reference signal
is available between IOB connector.
Check for disconnected, grounded, or
shorted wiring. Check for condensation in
transducer connector.
Check Oil Supply pressure transducer
wiring. Confirm that 5 V reference signal
is available between IOB connectors.
Check for disconnected, grounded, or
shorted wiring. Check for condensation in
transducer connector.
Check Pump Inlet pressure transducer
wiring. Confirm that 5 V reference signal
is available between IOB connectors.
Check for disconnected, grounded, or
shorted wiring. Check for condensation in
transducer connector.
Check Bearing Inlet pressure transducer
wiring. Confirm that 5 V reference signal
is available between IOB connectors.
Check for disconnected, grounded, or
shorted wiring. Check for condensation in
transducer connector.
During prestart process,
if all of the bearing temperature sensors
are in the range
AND
{
For 19XR6&7 and 19XRF chiller,
if MTRB1 or MTRB2 or MTRB3 or MTRB4
is larger than tb_alt2 minus 10F
OR
For 19XR2~5/C/D/E/V chiller,
if MTRB is larger than tb_alert minus 10F
OR
For 19DV chiller,
if CBH1 or CBH2 is larger than tb_alt3
minus 10F
}
Check Comp Motor Wind Temp in
Temperature screen.
Check motor temperature sensor for wiring
and accuracy to IOB connector.
Check motor cooling line and isolation
valves for proper operation, or restrictions,
check refrigerant filter/drier.
Check for excessive starts within a short
time span.
Check Comp Motor Temp Override
setting.
Check Comp Discharge Temp in screen.
Allow compressor discharge temperature
sensor to cool.
