SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
–
TM
SmartVu
2.3
Dec 4, 2020
44 OF 168
Controls IOM
Conf irm the unit shut-down or return to the previous screen.
4.7. Alarm Screen
To access Alarm screen, press the following button:
. More detailed contents please refer to
chapter 6.
4.8. Menu Screen
To access Main menu, press the following button:
Touch the items to access the corresponding table/menu.
Navigation through tables
44
