24 AUTO_DEM -
25 AUTO_RES -
26 REF_LEAK -
27 VFD_IN -
28 GV1_MA -
29 GV2_MA -
30 VFDC_MA -
31 DMP_ACTP -
32 DMP_MA -
33 HGBPACTP -
34 HGBP_MA -
35 TRIPR OPEN_CLOSE
36 SHAFTDIS OPEN_CLOSE
37 POW_FDB NO_YES
38 FC_SS OFF_ON
39 CUS_ALE OPEN_CLOSE
40 PGLE_LO OPEN_CLOSE
41 PGLE_HI OPEN_CLOSE
42 HF_LS OPEN_CLOSE
*Depends on the selected language (English by default).
OUTPUTS - Outputs Status
Name Range
1 GV1_OUT -
2 GV1_DEC OFF_ON
