Carrier SmartVu Control Manual page 24

IOB3
AI6
IOB3
AI7
IOB3 AI8
IOB3
AI9
IOB3
AI10
IOB3 AI11
IOB3 AO1
IOB3 AO2
IOB3 AO3
IOB3
DI1
IOB3
DI2
IOB3 DI3
IOB3
DI4
IOB3
DO1
IOB3
DO2
IOB3 DO3
IOB3 DO4
IOB4 AI1
IOB4 AI2
IOB4
AI3
IOB4
AI4
SRDC-UG-2-14-000
19 Series Carrier®
TM
SmartVu
Controls IOM
[If guide vane1 Type is Analog]
GV1 Pos Feedback
[If guide vane1 Type is Digital]
Guide Vane 1 Actual Ohms
[If Common Sensor Option is enable]
Common CHWS Temp
Auto Water Temp Reset
[If Common Sensor Option is enable]
Common CHWR Temp
Dample Valve Feedback
Head Pressure Output
Head Pressure Output 2
EC Valve Feedback Fully Open
EC Valve Feedback Fully Close
Spare Saf ety
EC Valve Solenoid / Open
EC Valve Close
Chilled Water Pump
Condenser Water Pump
Heat Reclaim Entering Temp
Heat Reclaim Leaving Temp
[If Water Pressure Option is PD TRD
(transducers)]
Evap Enter Water Volts
[If Water Pressure Option is PD TRM
(transmitter)]
Chilled Water Pres Drop
[If Water Pressure Option is PD TRD
(transducers)]
Evap Leave Water Volts
REVISION
–
2.3
DATE PAGE
Dec 4, 2020 24 OF 168
For analog type guide
vane
For digital type guide vane
Used f or lead lag option
User option
Used f or lead lag option
For analog type damper
valve
User option
User option
Used f or Continues or
ON/OFF type HGBP valve
Used f or Continues or
ON/OFF type HGBP valve
User option, normal open
Used f or Continues or
ON/OFF type HGBP valve
Used f or Continues or
ON/OFF type HGBP valve
User option
User option
User Option
User Option
User option, if IOB4
installed, same as follows
User option
