Carrier SmartVu Control Manual page 140

29 hdpv_tgt -
30 HDPV_OUT -
31 HDPV_OU2 -
32 TFR_HIGH OFF_ON
33 TFR_LOW OFF_ON
34 DIFF_OUT -
35 LLC_EXVO -
36 llc_exvt -
37 OP_VFD -
38 op_vfd_t -
39 POW_REQ OFF_ON
40 FC_MODE NO_YES
*Depends on the selected language (English by default).
DV_OUT - 19DV Outputs Status
Name Range
1 REF_PUMP OFF_ON
2 GV2_OUT -
3 ECBY_VLV OFF_ON
4 ECON_IV OFF_ON
5 COND_CV OFF_ON
6 EVAP_CV OFF_ON
7 EVAP_DCV OFF_ON
8 COND_DCV OFF_ON
9 COND_PSV OFF_ON
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
0 %
0 mA
0 mA
OFF -
OFF -
0 mA
0 mA
0 %
0 mA
0 %
OFF -
NO -
Default Unit
OFF -
0 mA
OFF -
OFF -
OFF -
OFF -
OFF -
OFF -
OFF -
REVISION DATE
2.3 Dec 4, 2020
Head Pres Valve Tgt Pos
Head Pres Output mA
Head Pres2 Output mA
Tower Fan Relay High
Tower Fan Relay Low
Diffuser Output mA
Liquid Level EXV Output
Liquid Level EXV Target
Oil Pump VFD Output mA
Oil Pump VFD Target
Marine Pwr Req Output
Free Cooling Mode
Displayed text*
Refrigerant Pump
Guide Vane2 Output
ECO Liquid Bypass Valve
ECO Isolation VLV
Cond Valve (Ref Lube)
Evap Valve (Ref Lube)
Evaporator Drain Valve
Condenser Drain Valve
Purge Cond Valve
PAGE
140 OF 168
140
