High speed motor end
bearing temperature
sensor
High speed comp end
bearing temperature
sensor
Comp thrust bearing oil
temperature sensor
1st Stage Bearing
Temp
2nd Stage Bearing
Temp
Bearing Ref Supply
Temp
Motor winding
temperature sensors
Oil sump temperature
sensor
Oil supply temperature
sensor
The temperature sensor range is -40 ~ +245°F.
SRDC-UG-2-14-000
19 Series Carrier®
TM
SmartVu
Controls IOM
measure the high speed motor end bearing
temperature
measure the high speed compressor end
bearing temperature
Measure the compressor thrust bearing oil
temperature
st
Measure the 1 stage bearing temperature
nd
Measure the 2 stage bearing temperature
Measure the bearing ref supply temperature Standard for 19DV
The 3 sensors measure the temperature of
compressor motor windings
measures the compressor sump
temperature of oil
measures the oil temperature in the oil
discharge piping
REVISION
–
2.3
DATE PAGE
Dec 4, 2020 19 OF 168
Standard for 19XR6/7
Standard for 19XR6/7
Standard for
19XR2~E/V/D
Standard for 19DV
Standard for 19DV
Standard for
19XR2~E/V/D,
19XR6/7 and 19DV
19XR2~E/V/D and
19DV only has 1
sensor.
Standard for
19XR2~E/V/D and
19XR6/7
Standard for
19XR2~E/V/D and
19XR6/7
