22 Q_DMPCL OFF_ON
23 Q_ALM OFF_ON
24 Q_ALE OFF_ON
25 Q_CDWP OFF_ON
26 CDW_FLOW NO_YES
27 CDW_DT -22.22 to 136.11
-40 to 245
28 Q_CHWP OFF_ON
29 CHW_FLOW NO_YES
30 CHW_DT -22.22 to 136.11
-40 to 245
31 Q_LLCEXV 0 to 100
32 Q_VSSV OFF_ON
33 Q_LQBP 4 to 20
34 Q_FCMODE OFF_ON
35 Q_LOWFAN OFF_ON
36 Q_HIFAN OFF_ON
37 Q_TRIPR OFF_ON
38 QVFDLOCK OFF_ON
*Depends on the selected language (English by default).
QCK_DV - 19DV Quick Test
Name Range
1 QCK_TEST DSABLE_ENABLE
2 Q_GV2POS 0 to 100
3 Q_CONDSV OFF_ON
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
OFF -
OFF -
OFF -
OFF -
NO -
0.00 ^C
0 ^F
OFF -
NO -
0.00 ^C
0 ^F
0 %
OFF -
4 mA
OFF -
OFF -
OFF -
OFF -
OFF -
Default Unit
DSABLE -
0 %
OFF -
REVISION DATE
2.3 Dec 4, 2020
ECO DMP VLV Close
Alarm Output
Alert Output
Condenser Water Pump
Condenser Water Flow
Condenser Water Delta T
Chilled Water Pump
Chilled Water Flow
Chilled Water Delta T
Liquid Level EXV
ECO Vapor SV
ECO LBP VLV mA
Free Cooling Mode
Low Speed Tower Fan
High Speed Tower Fan
Shunt Trip Relay
Danfoss VFD Interlock
Displayed text*
Quick Test Enable
Guide Vane 2 Pos
Cond CV (DV Lube Sled)
PAGE
164 OF 168
