Carrier SmartVu Control Manual page 33

IOB1
AI5
IOB1 AI6
IOB1 AI7
IOB1 AI8
IOB1 AI9
IOB1 AI10
IOB1 AI11
IOB1
AO1
IOB1 AO2
IOB1 AO3
IOB1
DI1
IOB1
DI2
IOB1
DI3
IOB1
DI4
IOB1 DO1
IOB1 DO2
IOB1
DO3
IOB1 DO4
IOB2 AI1
IOB2 AI2
IOB2 AI3
IOB2 AI4
IOB2
AI5
IOB2 AI6
IOB2 AI7
IOB2 AI8
IOB2 AI9
SRDC-UG-2-14-000
19 Series Carrier®
SmartVu
Controls IOM
[If Evap Liquid Temp Opt is enable]
Evap. Refrigerant Liquid Temperature
Comp Discharge Temperature
Condenser Pressure
Evaporator Pressure
EC Valve Feedback
FS VFD Load Current
Chiller Status (Analog)
Oil EXV Output
EC Valve Output mA
Chiller Lockout Input
Spare Safety
[If ISM Input is disable]
Remote Contact Input
[If ISM Input is disable]
Remote Emergency Stop Input
Chilled Water Pump
Condenser Water Pump
Chiller Alarm Relay
Danfoss VFD Interlock
Economizer Pressure
High Speed CE Brg Temp
Oil Sump Temperature
Oil Supply Temperature
[If guide vane1 Type is Analog]
GV1 Pos Feedback
[If guide vane1 Type is Digital]
Guide Vane 1 Actual Ohms
Oil Supply Pressure
Oil Sump Pressure
Motor Winding Temperature 1
Motor Winding Temperature 2
REVISION
–
TM
2.3
DATE PAGE
Dec 4, 2020 33 OF 168
For free standing VFD
User option, 4~20mA
4mA=OFF
8mA=Tripout
12mA=Shutdown
20mA=Running
User option,normal
open
User option,normal
open
User option, "Closed"
indicates Turn ON the
chiller
User option, "Closed"
indicates chiller
emergency stop
User option
User option
User option, 24VAC
output, recommend
with external power
supply
For analog type guide
vane
For digital type guide
vane
33
