CFGSURGE - Surge Correction
Name Range
1 sgl_cfg 0 to 1
2 blank -
3 gv1c_sel 0 to 1
4 blank -
5 dts_max 0.00 to 83.33
0 to 150
6 dts_min 0.00 to 83.33
0 to 150
7 pr_ful 1 to 5
8 pr_min 1 to 5
9 gv1_dful 80 to 120
10 gv1_dmed 10 to 40
11 gv1_dmin 0 to 10
12 gv1_dmax 90 to 120
13 gv1_pmin 0 to 100
14 gv1_pful 0 to 100
15 sgl_off 0.56 to 1.67
1 to 3
16 sgl_loff 0.28 to 1.67
0.5 to 3
17 sgl_hoff 0.06 to 1.67
SRDC-UG-2-14-000
19 Series Carrier®
–
TM
SmartVu
Controls IOM
- -
Default Unit
0 -
- -
0 -
- -
38.89 ^C
70 ^F
25.00 ^C
45 ^F
3 -
1.5 -
88 -
27 -
2 -
109 -
5 %
100 %
0.83 ^C
1.5 ^F
0.56 ^C
1 ^F
0.56 ^C
REVISION DATE
2.3 Dec 4, 2020
1m/4h=2, Comb. 0&1=3
Displayed text*
Surge Line Configuration
PR = 0, Delta T = 1
IGV1 Pos Configuration
Degree =0, Percentage =1
Surge Delta Tsmax
Surge Delta Tsmin
PR at Full Load Opening
PR at Minimum Opening
IGV1 Full Load Open Deg
Sound Ctrl IGV1 Open Deg
IGV1 Minimum Open Deg
IGV1 Actuator Max Deg
IGV1 Minimum Position
IGV1 Full Load Position
Surge Line Offset
Surge Line Lower DB
Surge Line Upper DB
